Specifications#
- Brand
- Canon
- Model
- EOS R6 Mark II
- Also known as
- Canon EOS R6m2
- Camera type
- Mirrorless
- Released
- 2022-12-15
- Lens mount
- Canon RF
- Sensor size
- 36.0 × 24.0 mm (Full frame (35 mm))
- Crop factor
- 1.00×
- Resolution
- 24.2 MP (6,000 × 4,000 px)
- ISO range
- 100 – 102,400
- Fastest shutter
- 1/8,000 s
- Continuous shooting
- 40 fps
- Max video resolution
- 6K
- Weight
- 588 g (20.7 oz)
- Sensor
- Dual-pixel CMOS sensor
- Sensor type
- Full-frame 35mm
- Viewfinder
- 3.69-million dot OLED EVF
- Battery
- LP-E6NH, LP-E6N, LP-E6;; 320 shots (EVF); 580 shots (LCD) (CIPA rating)
- Dimensions
- 138.4 × 98.4 × 88.4 mm
- Predecessor
- Canon EOS R6
- Successor
- Canon EOS R6 Mark III
- Made in
- Japan
- Launch price
- $2,499.00 (body only); $2,799 (with RF 24-105 F4-7.1 IS STM); $3,599 (with RF 24-105 F4 L IS USM)
- Video
- 6K/60p (with external recorder); 4K/60p internal (oversampled from 6K)
Specifications merged from Wikipedia, Wikidata and Lensfun. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.00 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 10 mm | 10 mm | 121.9° | 100.4° | 130.4° |
| 12 mm | 12 mm | 112.6° | 90.0° | 122.0° |
| 14 mm | 14 mm | 104.3° | 81.2° | 114.2° |
| 16 mm | 16 mm | 96.7° | 73.7° | 107.0° |
| 18 mm | 18 mm | 90.0° | 67.4° | 100.5° |
| 20 mm | 20 mm | 84.0° | 61.9° | 94.5° |
| 24 mm | 24 mm | 73.7° | 53.1° | 84.1° |
| 28 mm | 28 mm | 65.5° | 46.4° | 75.4° |
| 35 mm | 35 mm | 54.4° | 37.8° | 63.4° |
| 40 mm | 40 mm | 48.5° | 33.4° | 56.8° |
| 50 mm | 50 mm | 39.6° | 27.0° | 46.8° |
| 56 mm | 56 mm | 35.6° | 24.2° | 42.2° |
| 70 mm | 70 mm | 28.8° | 19.5° | 34.3° |
| 85 mm | 85 mm | 23.9° | 16.1° | 28.6° |
| 100 mm | 100 mm | 20.4° | 13.7° | 24.4° |
| 135 mm | 135 mm | 15.2° | 10.2° | 18.2° |
| 200 mm | 200 mm | 10.3° | 6.9° | 12.3° |
| 300 mm | 300 mm | 6.9° | 4.6° | 8.2° |
| 400 mm | 400 mm | 5.2° | 3.4° | 6.2° |
| 600 mm | 600 mm | 3.4° | 2.3° | 4.1° |
| 800 mm | 800 mm | 2.6° | 1.7° | 3.1° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 30.0 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 22 mm | f/1.8 | 5.3 cm | 22.1 cm | 92.8 cm | 2.24 m | 8.03 m | ∞ | 8.98 m |
| 22 mm | f/2.8 | 8.4 cm | 35.0 cm | 1.56 m | 4.23 m | 34.1 m | ∞ | 5.78 m |
| 22 mm | f/4 | 12.0 cm | 51.5 cm | 2.58 m | 9.74 m | ∞ | ∞ | 4.06 m |
| 22 mm | f/8 | 25.1 cm | 1.27 m | 103 m | ∞ | ∞ | ∞ | 2.04 m |
| 43 mm | f/1.8 | 1.3 cm | 5.6 cm | 22.9 cm | 52.2 cm | 1.48 m | 6.35 m | 34.3 m |
| 43 mm | f/2.8 | 2.1 cm | 8.7 cm | 35.8 cm | 82.1 cm | 2.37 m | 11.4 m | 22.1 m |
| 43 mm | f/4 | 3.0 cm | 12.5 cm | 51.6 cm | 1.20 m | 3.59 m | 22.2 m | 15.5 m |
| 43 mm | f/8 | 6.0 cm | 25.2 cm | 1.09 m | 2.70 m | 11.0 m | ∞ | 7.75 m |
| 73 mm | f/1.8 | 0.4 cm | 1.9 cm | 7.8 cm | 17.8 cm | 50.1 cm | 2.03 m | 98.8 m |
| 73 mm | f/2.8 | 0.7 cm | 2.9 cm | 12.2 cm | 27.7 cm | 78.1 cm | 3.21 m | 63.5 m |
| 73 mm | f/4 | 1.0 cm | 4.2 cm | 17.4 cm | 39.7 cm | 1.12 m | 4.71 m | 44.5 m |
| 73 mm | f/8 | 1.9 cm | 8.4 cm | 35.0 cm | 80.5 cm | 2.33 m | 11.2 m | 22.3 m |
| 120 mm | f/1.8 | 0.1 cm | 0.7 cm | 2.8 cm | 6.5 cm | 18.3 cm | 74.2 cm | 267 m |
| 120 mm | f/2.8 | 0.2 cm | 1.0 cm | 4.4 cm | 10.1 cm | 28.5 cm | 1.16 m | 172 m |
| 120 mm | f/4 | 0.3 cm | 1.5 cm | 6.3 cm | 14.4 cm | 40.7 cm | 1.66 m | 120 m |
| 120 mm | f/8 | 0.6 cm | 2.9 cm | 12.5 cm | 28.9 cm | 81.9 cm | 3.39 m | 60.1 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 6.00 µm pixels, diffraction starts to soften pixel-level detail around f/8.9. For maximum sharpness keep landscapes between f/4.9 and f/9; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 0.6 px | sharp |
| f/4 | 5.4 µm | 0.9 px | sharp |
| f/5.6 | 7.5 µm | 1.3 px | sharp |
| f/8 | 10.7 µm | 1.8 px | sharp |
| f/11 | 14.8 µm | 2.5 px | slight softening |
| f/16 | 21.5 µm | 3.6 px | visibly soft |
| f/22 | 29.5 µm | 4.9 px | visibly soft |
Maximum print sizes#
At 24.2 MP the Canon EOS R6 Mark II produces 6,000 × 4,000 pixel images. See the 24 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 20.0 × 13.3 in | 51 × 34 cm |
| 240 DPI | Fine-art inkjet | 25.0 × 16.7 in | 64 × 42 cm |
| 200 DPI | Wall print | 30.0 × 20.0 in | 76 × 51 cm |
| 150 DPI | Poster, viewed from 1 m+ | 40.0 × 26.7 in | 102 × 68 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 14 mm (14 mm eq.) | 35.7 s | 17.4 s | 19.9 s | 22.9 s |
| 20 mm (20 mm eq.) | 25.0 s | 12.2 s | 13.9 s | 16.0 s |
| 24 mm (24 mm eq.) | 20.8 s | 10.1 s | 11.6 s | 13.3 s |
| 35 mm (35 mm eq.) | 14.3 s | 6.9 s | 7.9 s | 9.1 s |
| 50 mm (50 mm eq.) | 10.0 s | 4.9 s | 5.6 s | 6.4 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 24 mm | 1/25 s | 0.3 s | 1.3 s |
| 50 mm | 1/50 s | 1/6 s | 0.6 s |
| 100 mm | 1/100 s | 1/13 s | 0.3 s |
| 200 mm | 1/200 s | 1/25 s | 1/6 s |
Lenses for the Canon EOS R6 Mark II#
Native Canon RF lenses in our database (48 total). Also adaptable: T-mount (T2), Canon EF, M42 screw mount, Deckel (DKL), Canon EF-S, M39 / LTM (Leica thread).
- Canon RF-S 18-150mm F3.5-6.3 IS STM 18–150 mm
- Canon RF 24mm F1.4 L VCM 24 mm
- Canon RF 24mm F1.8 MACRO IS STM 24 mm
- Canon RF 28-70mm F2.8 IS STM 28–70 mm
- Canon RF 50mm F1.2 L USM 50 mm
- Canon RF 50mm F1.4 L VCM 50 mm
- Canon RF 135mm F1.8L IS USM 135 mm
- Canon RF 10-20mm f/4L IS STM 10–20 mm
- Canon RF-S 10-18mm F4.5-6.3 IS STM 10–18 mm
- Laowa 10mm f/2.8 Zero-D FF 10 mm
- Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
- Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
- Canon RF 14-35mm F4 L IS USM 14–35 mm
- Canon RF 15-30mm F4.5-6.3 IS STM 15–30 mm
- Canon RF 15-35mm F2.8L IS USM 15–35 mm
- Laowa 15mm f/2.0 Zero-D 15 mm
- Canon RF 16mm F2.8 STM 16 mm
- Sigma 16-300mm F3.5-6.7 DC OS | C 16–300 mm
- Sigma 16mm f/1.4 DC DN Contemporary 16 mm
- Sigma 17-40mm F1.8 DC | Art 025 17–40 mm
- Tamron 17-70mm F/2.8 Di III-A VC RXD 17–70 mm
- Canon RF-S 18-45mm F4.5-6.3 IS STM 18–45 mm
- Sigma 18-50mm F2.8 DC DN | Contemporary 021 18–50 mm
- Tamron 18-300mm F3.5-6.3 B061 RF 18–300 mm
- Canon RF 24-105mm F4-7.1 IS STM 24–105 mm
- Canon RF 24-105mm F4L IS USM 24–105 mm
- Canon RF 24-240mm F4-6.3 IS USM 24–240 mm
- Canon RF 24-50mm F4.5-6.3 IS STM 24–50 mm
- Canon RF 24-70mm F2.8L IS USM 24–70 mm
- Canon RF 28-70mm F2 L USM 28–70 mm
- Canon RF 28mm F2.8 STM 28 mm
- Sigma 30mm f/1.4 DC DN 30 mm
- Canon RF 35mm F1.4 L VCM 35 mm
- Canon RF 35mm F1.8 MACRO IS STM 35 mm
- Canon RF 45mm F1.2 STM 45 mm
- Canon RF 50mm F1.8 STM 50 mm
Similar cameras#
Other Full frame (35 mm) cameras from around the same time.
- Sony α7R V 2022
- Nikon Z8 2023
- Nikon Zf 2023
- Nikon Z9 2021
- Sony FX3 2021
- Sony α1 2021
- Nikon Z6III 2024
- Sony α1 II 2024
- Sony α9 III 2024
- Nikon Z5 2020
- Sony α7S III 2020
- Panasonic Lumix DC-S5M2 2023
Frequently asked questions#
What is the crop factor of the Canon EOS R6 Mark II?
The Canon EOS R6 Mark II has a crop factor of 1.00× relative to 35 mm full frame (diagonal 43.3 mm vs 43.3 mm).
What size is the Canon EOS R6 Mark II sensor?
36.0 × 24.0 mm (Full frame (35 mm)), an area of 864 mm² — 100% of full frame.
Is the Canon EOS R6 Mark II full frame?
Yes — its sensor is the same 36 × 24 mm size as 35 mm film.
How many megapixels does the Canon EOS R6 Mark II have?
24.2 megapixels (6,000 × 4,000 pixels), enough for a 20 × 13 inch print at 300 DPI.
What lens mount does the Canon EOS R6 Mark II use?
The Canon EOS R6 Mark II uses the Canon RF (flange distance 20.00 mm).
How long can I expose the night sky with the Canon EOS R6 Mark II?
With a 20 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 14 s.
