Canon EOS D30 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Canon EOS D30?

The Canon EOS D30 has a crop factor of 1.59× relative to 35 mm full frame (diagonal 27.3 mm vs 43.3 mm).

1.59×

Crop factor

22.7×15.1 mm

Sensor size

343 mm²

Area · 40% of full frame

3.1 MP

Resolution

10.51 µm

Pixel pitch

f/15.7

Diffraction-limited aperture

2000

Release year

Specifications#

Brand: Canon
Model: EOS D30
Camera type: DSLR
Released: 2000-01-01
Lens mount: Canon EF-S
Sensor size: 22.7 × 15.1 mm (APS-C (Canon))
Crop factor: 1.59×
Resolution: 3.1 MP (2,160 × 1,440 px)
Continuous shooting: 3 fps
Weight: 780 g (27.5 oz)
Sensor: CMOS
Storage: CompactFlash (CF) (Type I or Type II) and MicroDrive (MD)
Viewfinder: Optical
AF points / area: 3 points (1 + 1)
Metering: TTL, full aperture, zones
Exposure modes: Full auto, programmed, shutter-priority, aperture priority, manual
Shutter: electronic focal plane
Flash: built-in, pop-up
Battery: Li-Ion BP-511 rechargeable
Lens: Interchangeable
Predecessor: Canon EOS D2000
Successor: Canon EOS D60
Drive: up to 3.0 frame/s, max 8 frames

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Canon EOS D30 sensor (highlighted) drawn to scale against common formats. Its area is 40% of a full-frame sensor, which collects about 1.3 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.59 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	13 mm	109.6°	86.7°	119.2°
10 mm	16 mm	97.2°	74.1°	107.5°
12 mm	19 mm	86.8°	64.4°	97.3°
14 mm	22 mm	78.1°	56.7°	88.5°
16 mm	25 mm	70.7°	50.5°	80.9°
18 mm	29 mm	64.5°	45.5°	74.3°
20 mm	32 mm	59.1°	41.4°	68.6°
24 mm	38 mm	50.6°	34.9°	59.2°
28 mm	44 mm	44.1°	30.2°	51.9°
35 mm	56 mm	35.9°	24.3°	42.6°
40 mm	63 mm	31.7°	21.4°	37.6°
50 mm	79 mm	25.6°	17.2°	30.5°
56 mm	89 mm	22.9°	15.4°	27.4°
70 mm	111 mm	18.4°	12.3°	22.0°
85 mm	135 mm	15.2°	10.2°	18.2°
100 mm	159 mm	13.0°	8.6°	15.5°
135 mm	214 mm	9.6°	6.4°	11.5°
200 mm	317 mm	6.5°	4.3°	7.8°
300 mm	476 mm	4.3°	2.9°	5.2°
400 mm	635 mm	3.3°	2.2°	3.9°
600 mm	952 mm	2.2°	1.4°	2.6°
800 mm	1270 mm	1.6°	1.1°	2.0°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 18.9 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
14 mm	f/1.8	8.5 cm	35.3 cm	1.57 m	4.25 m	34.5 m	∞	5.77 m
14 mm	f/2.8	13.4 cm	57.3 cm	3.01 m	13.8 m	∞	∞	3.72 m
14 mm	f/4	19.4 cm	88.9 cm	7.42 m	∞	∞	∞	2.61 m
14 mm	f/8	43.6 cm	3.61 m	∞	∞	∞	∞	1.31 m
27 mm	f/1.8	2.2 cm	9.1 cm	37.2 cm	84.9 cm	2.45 m	11.9 m	21.5 m
27 mm	f/2.8	3.4 cm	14.2 cm	58.5 cm	1.36 m	4.15 m	30.4 m	13.8 m
27 mm	f/4	4.9 cm	20.4 cm	85.4 cm	2.04 m	7.03 m	∞	9.67 m
27 mm	f/8	9.9 cm	42.1 cm	1.97 m	5.97 m	∞	∞	4.85 m
46 mm	f/1.8	0.7 cm	3.1 cm	12.6 cm	28.6 cm	80.2 cm	3.29 m	62.2 m
46 mm	f/2.8	1.1 cm	4.8 cm	19.6 cm	44.6 cm	1.26 m	5.31 m	40.0 m
46 mm	f/4	1.6 cm	6.8 cm	28.1 cm	64.1 cm	1.83 m	8.14 m	28.0 m
46 mm	f/8	3.2 cm	13.7 cm	57.0 cm	1.33 m	4.05 m	28.8 m	14.0 m
76 mm	f/1.8	0.2 cm	1.1 cm	4.5 cm	10.3 cm	29.0 cm	1.17 m	170 m
76 mm	f/2.8	0.4 cm	1.7 cm	7.1 cm	16.1 cm	45.2 cm	1.83 m	109 m
76 mm	f/4	0.6 cm	2.4 cm	10.1 cm	23.0 cm	64.7 cm	2.64 m	76.5 m
76 mm	f/8	1.1 cm	4.8 cm	20.2 cm	46.2 cm	1.31 m	5.57 m	38.3 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 27 mm
f/1.2	f/1.9	32.2 m
f/1.4	f/2.2	27.6 m
f/1.8	f/2.9	21.5 m
f/2	f/3.2	19.3 m
f/2.8	f/4.4	13.8 m
f/4	f/6.3	9.67 m
f/5.6	f/8.9	6.91 m
f/8	f/12.7	4.85 m

Diffraction & pixel pitch#

With 10.51 µm pixels, diffraction starts to soften pixel-level detail around f/15.7. For maximum sharpness keep landscapes between f/8.6 and f/16; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	0.4 px	sharp
f/4	5.4 µm	0.5 px	sharp
f/5.6	7.5 µm	0.7 px	sharp
f/8	10.7 µm	1.0 px	sharp
f/11	14.8 µm	1.4 px	sharp
f/16	21.5 µm	2.0 px	slight softening
f/22	29.5 µm	2.8 px	slight softening

Maximum print sizes#

At 3.1 MP the Canon EOS D30 produces 2,160 × 1,440 pixel images. See the 3 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	7.2 × 4.8 in	18 × 12 cm
240 DPI	Fine-art inkjet	9.0 × 6.0 in	23 × 15 cm
200 DPI	Wall print	10.8 × 7.2 in	27 × 18 cm
150 DPI	Poster, viewed from 1 m+	14.4 × 9.6 in	37 × 24 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
9 mm (14 mm eq.)	35.0 s	42.0 s	45.9 s	50.6 s
13 mm (21 mm eq.)	24.2 s	29.1 s	31.8 s	35.0 s
15 mm (24 mm eq.)	21.0 s	25.2 s	27.6 s	30.4 s
22 mm (35 mm eq.)	14.3 s	17.2 s	18.8 s	20.7 s
32 mm (51 mm eq.)	9.8 s	11.8 s	12.9 s	14.2 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
15 mm	1/25 s	0.3 s	1.3 s
32 mm	1/50 s	1/6 s	0.6 s
63 mm	1/100 s	1/13 s	0.3 s
126 mm	1/200 s	1/25 s	1/6 s

Lenses for the Canon EOS D30#

Native Canon EF-S lenses in our database (29 total). Also adaptable: T-mount (T2), Canon EF, M42 screw mount, Deckel (DKL), Tamron Adaptall, M39 / LTM (Leica thread).

Canon EF-S 18-135mm f/3.5-5.6 IS 18–135 mm
Canon EF-S 18-135mm f/3.5-5.6 IS STM 18–135 mm
Canon EF-S 55-250mm f/4-5.6 IS STM 55–250 mm
Canon EF-S 60mm f/2.8 Macro USM 60 mm
Canon EF 75-300mm F4-5.6 III 75–300 mm
Canon EF-S 10-18mm f/4.5-5.6 IS STM 10–18 mm
Canon EF-S 10-22mm f/3.5-4.5 USM 10–22 mm
Sigma 10-20mm f/3.5 EX DC HSM 10–20 mm
Tokina atx-i 11-16mm F2.8 CF 11–16 mm
Canon EF-S 15-85mm f/3.5-5.6 IS USM 15–85 mm
Canon EF-S 17-55mm f/2.8 IS USM 17–55 mm
Canon EF-S 17-85mm f/4-5.6 IS USM 17–85 mm
Canon EF-S 18-135mm f/3.5-5.6 IS USM 18–135 mm
Canon EF-S 18-200mm f/3.5-5.6 IS 18–200 mm
Canon EF-S 18-55mm f/3.5-5.6 18–55 mm
Canon EF-S 18-55mm f/3.5-5.6 II 18–55 mm
Canon EF-S 18-55mm f/3.5-5.6 III 18–55 mm
Canon EF-S 18-55mm f/3.5-5.6 IS 18–55 mm
Canon EF-S 18-55mm f/3.5-5.6 IS II 18–55 mm
Canon EF-S 18-55mm f/3.5-5.6 IS STM 18–55 mm
Canon EF-S 18-55mm f/4-5.6 IS STM 18–55 mm
Sigma 18-200mm f/3.5-6.3 DC Macro OS HSM 18–200 mm
Canon EF-S 24mm f/2.8 STM 24 mm
Samyang 35mm f/1.4 AS UMC 35 mm
Canon EF-S 55-250mm f/4-5.6 IS 55–250 mm
Canon EF-S 55-250mm f/4-5.6 IS II 55–250 mm
Sigma 60-600mm F4.5-6.3 DG OS HSM | Sports 018 60–600 mm
Sigma 60-600mm F4.5-6.3 DG OS HSM | Sports 018 + 1.4× ext. 60–600 mm
Sigma 90mm f/2.8 Macro AF 90 mm

Frequently asked questions#

What is the crop factor of the Canon EOS D30?

The Canon EOS D30 has a crop factor of 1.59× relative to 35 mm full frame (diagonal 27.3 mm vs 43.3 mm).

What size is the Canon EOS D30 sensor?

22.7 × 15.1 mm (APS-C (Canon)), an area of 343 mm² — 40% of full frame.

Is the Canon EOS D30 full frame?

No — its sensor is APS-C (Canon), which is 2.5× smaller in area than full frame.

How many megapixels does the Canon EOS D30 have?

3.1 megapixels (2,160 × 1,440 pixels), enough for a 7 × 5 inch print at 300 DPI.

What lens mount does the Canon EOS D30 use?

The Canon EOS D30 uses the Canon EF-S (flange distance 44.00 mm).

How long can I expose the night sky with the Canon EOS D30?

With a 13 mm lens (21 mm equivalent) the 500 rule gives 24 s and the stricter NPF rule at f/2.8 gives 32 s.
