Specifications#
- Brand
- Canon
- Model
- EOS 30V
- Camera type
- Film SLR
- Released
- 2004
- Lens mount
- Canon EF
- Film format
- 135 film
- Image area
- 69.0 × 3.0 mm
- Crop factor
- 0.63×
- Weight
- 580 g (20.5 oz)
- Sensor type
- Film
- Focus
- TTL Phase Detection Autofocus (7 zone)
- Exposure modes
- PASM autoexposure; 35 zone evaluative metering
- Flash
- Built-in flash and E-TTL II flash metering with shoe mounted flash
- Dimensions
- 146.7 x 103 x 69 mm, 580g
- Predecessor
- Canon EOS 30 / 33 / 7 / Elan 7 / Elan 7e
- Production
- 2004-2007
Specifications merged from Wikipedia and Wikidata. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.63 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 13 mm | 117.3° | 8.2° | 117.4° |
| 23 mm | 14 mm | 112.6° | 7.5° | 112.7° |
| 28 mm | 18 mm | 101.9° | 6.1° | 101.9° |
| 32 mm | 20 mm | 94.3° | 5.4° | 94.4° |
| 35 mm | 22 mm | 89.2° | 4.9° | 89.2° |
| 45 mm | 28 mm | 75.0° | 3.8° | 75.0° |
| 55 mm | 34 mm | 64.2° | 3.1° | 64.2° |
| 63 mm | 39 mm | 57.4° | 2.7° | 57.5° |
| 80 mm | 50 mm | 46.7° | 2.1° | 46.7° |
| 90 mm | 56 mm | 41.9° | 1.9° | 42.0° |
| 110 mm | 69 mm | 34.8° | 1.6° | 34.9° |
| 120 mm | 75 mm | 32.1° | 1.4° | 32.1° |
| 150 mm | 94 mm | 25.9° | 1.1° | 25.9° |
| 180 mm | 113 mm | 21.7° | 1.0° | 21.7° |
| 250 mm | 157 mm | 15.7° | 0.7° | 15.7° |
| 350 mm | 219 mm | 11.3° | 0.5° | 11.3° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 47.9 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 34 mm | f/1.8 | 3.5 cm | 14.5 cm | 59.9 cm | 1.40 m | 4.29 m | 33.2 m | 13.4 m |
| 34 mm | f/2.8 | 5.4 cm | 22.7 cm | 96.2 cm | 2.34 m | 8.62 m | ∞ | 8.66 m |
| 34 mm | f/4 | 7.8 cm | 32.9 cm | 1.46 m | 3.89 m | 25.5 m | ∞ | 6.07 m |
| 34 mm | f/8 | 15.8 cm | 71.3 cm | 4.53 m | 174 m | ∞ | ∞ | 3.05 m |
| 69 mm | f/1.8 | 0.8 cm | 3.4 cm | 14.0 cm | 31.9 cm | 90.0 cm | 3.72 m | 55.3 m |
| 69 mm | f/2.8 | 1.2 cm | 5.2 cm | 21.8 cm | 49.9 cm | 1.42 m | 6.07 m | 35.6 m |
| 69 mm | f/4 | 1.7 cm | 7.5 cm | 31.3 cm | 71.8 cm | 2.07 m | 9.51 m | 24.9 m |
| 69 mm | f/8 | 3.5 cm | 15.1 cm | 63.7 cm | 1.50 m | 4.71 m | 44.2 m | 12.5 m |
| 117 mm | f/1.8 | 0.2 cm | 1.1 cm | 4.7 cm | 10.9 cm | 30.8 cm | 1.25 m | 159 m |
| 117 mm | f/2.8 | 0.4 cm | 1.7 cm | 7.4 cm | 17.0 cm | 47.9 cm | 1.95 m | 102 m |
| 117 mm | f/4 | 0.5 cm | 2.5 cm | 10.5 cm | 24.2 cm | 68.6 cm | 2.82 m | 71.6 m |
| 117 mm | f/8 | 1.1 cm | 4.9 cm | 21.1 cm | 48.7 cm | 1.39 m | 5.99 m | 35.8 m |
| 193 mm | f/1.8 | 0.1 cm | 0.4 cm | 1.7 cm | 3.9 cm | 11.1 cm | 45.4 cm | 432 m |
| 193 mm | f/2.8 | 0.1 cm | 0.6 cm | 2.6 cm | 6.1 cm | 17.3 cm | 70.7 cm | 278 m |
| 193 mm | f/4 | 0.2 cm | 0.8 cm | 3.7 cm | 8.7 cm | 24.7 cm | 1.01 m | 195 m |
| 193 mm | f/8 | 0.3 cm | 1.7 cm | 7.4 cm | 17.3 cm | 49.6 cm | 2.04 m | 97.4 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 22 mm (14 mm eq.) | 36.3 s |
| 32 mm (20 mm eq.) | 24.9 s |
| 38 mm (24 mm eq.) | 21.0 s |
| 56 mm (35 mm eq.) | 14.3 s |
| 80 mm (50 mm eq.) | 10.0 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 38 mm | 1/25 s | 0.3 s | 1.3 s |
| 80 mm | 1/50 s | 1/6 s | 0.6 s |
| 160 mm | 1/100 s | 1/13 s | 0.3 s |
| 319 mm | 1/200 s | 1/25 s | 1/6 s |
Lenses for the Canon EOS 30V#
Native Canon EF lenses in our database (267 total). Also adaptable: T-mount (T2), M42 screw mount, Deckel (DKL), Tamron Adaptall, M39 / LTM (Leica thread).
- Samyang 8mm f/3.5 Fish-Eye CS 8 mm
- Samyang 10mm f/2.8 ED AS NCS CS 10 mm
- Laowa 12mm f/2.8 Zero-D 12 mm
- Samyang 12mm f/2.8 Fish-Eye ED AS NCS 12 mm
- Canon EF 14mm f/2.8L II USM 14 mm
- Samyang 14mm f/2.8 AE ED AS IF UMC 14 mm
- Samyang AF 14mm f/2.8 14 mm
- Sigma 14mm f/1.8 DG HSM | A 14 mm
- Laowa 15mm F/4 Wide Angle Macro 15 mm
- Canon EF 16-35mm f/4L IS USM 16–35 mm
- Samyang 16mm f/2.0 ED AS UMC CS 16 mm
- Samyang 20mm f/1.8 ED AS UMC 20 mm
- Canon EF 24mm f/1.4L II USM 24 mm
- Samyang 24mm f/1.4 ED AS IF UMC 24 mm
- Samyang T-S 24mm f/3.5 ED AS UMC 24 mm
- Sigma 24mm f/1.4 DG HSM | A 24 mm
- Sigma 28mm F1.4 DG HSM | Art 28 mm
- Viltrox AF 33mm f/1.4 XF 33 mm
- Sigma 40mm F1.4 DG HSM | Art 40 mm
- Canon EF 50mm f/1.8 50 mm
- Canon EF 50mm f/1.8 II 50 mm
- Canon EF 50mm f/1.8 STM 50 mm
- Viltrox AF 56mm f/1.4 XF 56 mm
- Laowa 60mm f/2.8 2X Ultra-Macro 60 mm
- Canon EF 70-200mm f/2.8L IS II USM 70–200 mm
- Sigma 70-200mm F2.8 DG OS HSM | S 70–200 mm
- Samyang 85mm f/1.4 IF UMC Aspherical 85 mm
- Sigma 100-400mm F5-6.3 DG OS HSM | C 100–400 mm
- Sigma 100-400mm f/5-6.3 DG OS HSM | C +1.4x ext. 100–400 mm
- Sigma 105 mm F1.4 DG HSM Art 105 mm
- Samyang 135mm f/2 ED UMC 135 mm
- Sigma 4.5mm f/2.8 EX DC HSM circular fisheye 4.5 mm
- Canon EF 8-15mm f/4L Fisheye USM 8–15 mm
- Sigma 8-16mm f/4.5-5.6 DC HSM 8–16 mm
- Sigma 8mm f/3.5 EX DG circular fisheye 8 mm
- Samyang XP 10mm f/3.5 10 mm
Film stocks for the Canon EOS 30V#
Films currently made in 135 format.
- ADOX CHS 100 II ISO 100
- ADOX CMS 20 II PRO ISO 20
- ADOX Color Mission 200 ISO 200
- ADOX Color Mission Helios ISO 3
- ADOX HR-50 ISO 50
- ADOX Scala 50 ISO 50
- Agfa Copex Rapid ISO 50
- AgfaPhoto APX 100 ISO 100
- AgfaPhoto APX 200 ISO 200
- AgfaPhoto APX 400 ISO 400
- AgfaPhoto Color 400 ISO 400
- Argenti ARF+ Reporter Film Plus ISO 400
- Argenti Nanotomic X ISO 32
- Argenti Pan-X ISO 100
- Argenti Scale-X ISO 100
- Bergger Pancro 400 ISO 400
- CatLABS X FILM 320 ISO 320
- CatLABS X FILM 320 Pro ISO 320
Frequently asked questions#
What is the crop factor of the Canon EOS 30V?
The Canon EOS 30V has a crop factor of 0.63× relative to 35 mm full frame (diagonal 69.1 mm vs 43.3 mm).
What size is the Canon EOS 30V frame?
69.0 × 3.0 mm (135 film), an area of 207 mm² — 24% of full frame.
What lens mount does the Canon EOS 30V use?
The Canon EOS 30V uses the Canon EF (flange distance 44.00 mm).
How long can I expose the night sky with the Canon EOS 30V?
With a 32 mm lens (20 mm equivalent) the 500 rule gives 25 s.
