Specifications#
- Brand
- Canon
- Model
- EOS 300D
- Also known as
- Canon EOS 300D DIGITAL, Canon EOS DIGITAL REBEL, Canon EOS Digital Rebel, Canon EOS Kiss Digital
- Camera type
- DSLR
- Released
- 2003-01-01
- Lens mount
- Canon EF-S
- Sensor size
- 22.7 × 15.1 mm (APS-C (Canon))
- Crop factor
- 1.59×
- Resolution
- 6.3 MP (3,072 × 2,048 px)
- ISO range
- 100 – 1,600
- Continuous shooting
- 2.5 fps
- Weight
- 560 g (19.8 oz)
- Sensor
- 22.7 mm ; 15.1 mm CMOS
- Storage
- CompactFlash(CF) (Type I and Type II) / max 8GB
- Viewfinder
- Optical, pentamirror, 95% frame coverage, 0.88x magn.
- AF points / area
- 7 autofocus points
- Metering
- TTL, evaluative 35-zone, partial, center-weighted
- Exposure modes
- Full auto, programmed, shutter-priority, aperture priority, manual
- Shutter
- Focal-plane shutter, all speeds electronically controlled
- Flash
- Auto pop-up E-TTL auto flash
- Battery
- Li-Ion BP-511/512 rechargeable
- Dimensions
- 142 x 99 x 72.4 mm
- Lens
- Interchangeable (EF-S, EF)
- Successor
- Canon EOS 350D
- Drive
- 2.5 frame/s, up to 4 frames
Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.59 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 8 mm | 13 mm | 109.6° | 86.7° | 119.2° |
| 10 mm | 16 mm | 97.2° | 74.1° | 107.5° |
| 12 mm | 19 mm | 86.8° | 64.4° | 97.3° |
| 14 mm | 22 mm | 78.1° | 56.7° | 88.5° |
| 16 mm | 25 mm | 70.7° | 50.5° | 80.9° |
| 18 mm | 29 mm | 64.5° | 45.5° | 74.3° |
| 20 mm | 32 mm | 59.1° | 41.4° | 68.6° |
| 24 mm | 38 mm | 50.6° | 34.9° | 59.2° |
| 28 mm | 44 mm | 44.1° | 30.2° | 51.9° |
| 35 mm | 56 mm | 35.9° | 24.3° | 42.6° |
| 40 mm | 63 mm | 31.7° | 21.4° | 37.6° |
| 50 mm | 79 mm | 25.6° | 17.2° | 30.5° |
| 56 mm | 89 mm | 22.9° | 15.4° | 27.4° |
| 70 mm | 111 mm | 18.4° | 12.3° | 22.0° |
| 85 mm | 135 mm | 15.2° | 10.2° | 18.2° |
| 100 mm | 159 mm | 13.0° | 8.6° | 15.5° |
| 135 mm | 214 mm | 9.6° | 6.4° | 11.5° |
| 200 mm | 317 mm | 6.5° | 4.3° | 7.8° |
| 300 mm | 476 mm | 4.3° | 2.9° | 5.2° |
| 400 mm | 635 mm | 3.3° | 2.2° | 3.9° |
| 600 mm | 952 mm | 2.2° | 1.4° | 2.6° |
| 800 mm | 1270 mm | 1.6° | 1.1° | 2.0° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 18.9 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 14 mm | f/1.8 | 8.5 cm | 35.3 cm | 1.57 m | 4.25 m | 34.5 m | ∞ | 5.77 m |
| 14 mm | f/2.8 | 13.4 cm | 57.3 cm | 3.01 m | 13.8 m | ∞ | ∞ | 3.72 m |
| 14 mm | f/4 | 19.4 cm | 88.9 cm | 7.42 m | ∞ | ∞ | ∞ | 2.61 m |
| 14 mm | f/8 | 43.6 cm | 3.61 m | ∞ | ∞ | ∞ | ∞ | 1.31 m |
| 27 mm | f/1.8 | 2.2 cm | 9.1 cm | 37.2 cm | 84.9 cm | 2.45 m | 11.9 m | 21.5 m |
| 27 mm | f/2.8 | 3.4 cm | 14.2 cm | 58.5 cm | 1.36 m | 4.15 m | 30.4 m | 13.8 m |
| 27 mm | f/4 | 4.9 cm | 20.4 cm | 85.4 cm | 2.04 m | 7.03 m | ∞ | 9.67 m |
| 27 mm | f/8 | 9.9 cm | 42.1 cm | 1.97 m | 5.97 m | ∞ | ∞ | 4.85 m |
| 46 mm | f/1.8 | 0.7 cm | 3.1 cm | 12.6 cm | 28.6 cm | 80.2 cm | 3.29 m | 62.2 m |
| 46 mm | f/2.8 | 1.1 cm | 4.8 cm | 19.6 cm | 44.6 cm | 1.26 m | 5.31 m | 40.0 m |
| 46 mm | f/4 | 1.6 cm | 6.8 cm | 28.1 cm | 64.1 cm | 1.83 m | 8.14 m | 28.0 m |
| 46 mm | f/8 | 3.2 cm | 13.7 cm | 57.0 cm | 1.33 m | 4.05 m | 28.8 m | 14.0 m |
| 76 mm | f/1.8 | 0.2 cm | 1.1 cm | 4.5 cm | 10.3 cm | 29.0 cm | 1.17 m | 170 m |
| 76 mm | f/2.8 | 0.4 cm | 1.7 cm | 7.1 cm | 16.1 cm | 45.2 cm | 1.83 m | 109 m |
| 76 mm | f/4 | 0.6 cm | 2.4 cm | 10.1 cm | 23.0 cm | 64.7 cm | 2.64 m | 76.5 m |
| 76 mm | f/8 | 1.1 cm | 4.8 cm | 20.2 cm | 46.2 cm | 1.31 m | 5.57 m | 38.3 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 7.39 µm pixels, diffraction starts to soften pixel-level detail around f/11.0. For maximum sharpness keep landscapes between f/6.1 and f/11; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 0.5 px | sharp |
| f/4 | 5.4 µm | 0.7 px | sharp |
| f/5.6 | 7.5 µm | 1.0 px | sharp |
| f/8 | 10.7 µm | 1.5 px | sharp |
| f/11 | 14.8 µm | 2.0 px | sharp |
| f/16 | 21.5 µm | 2.9 px | slight softening |
| f/22 | 29.5 µm | 4.0 px | visibly soft |
Maximum print sizes#
At 6.3 MP the Canon EOS 300D produces 3,072 × 2,048 pixel images. See the 6 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 10.2 × 6.8 in | 26 × 17 cm |
| 240 DPI | Fine-art inkjet | 12.8 × 8.5 in | 33 × 22 cm |
| 200 DPI | Wall print | 15.4 × 10.2 in | 39 × 26 cm |
| 150 DPI | Poster, viewed from 1 m+ | 20.5 × 13.7 in | 52 × 35 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 9 mm (14 mm eq.) | 35.0 s | 31.6 s | 35.5 s | 40.2 s |
| 13 mm (21 mm eq.) | 24.2 s | 21.9 s | 24.6 s | 27.8 s |
| 15 mm (24 mm eq.) | 21.0 s | 19.0 s | 21.3 s | 24.1 s |
| 22 mm (35 mm eq.) | 14.3 s | 12.9 s | 14.5 s | 16.4 s |
| 32 mm (51 mm eq.) | 9.8 s | 8.9 s | 10.0 s | 11.3 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 15 mm | 1/25 s | 0.3 s | 1.3 s |
| 32 mm | 1/50 s | 1/6 s | 0.6 s |
| 63 mm | 1/100 s | 1/13 s | 0.3 s |
| 126 mm | 1/200 s | 1/25 s | 1/6 s |
Lenses for the Canon EOS 300D#
Native Canon EF-S lenses in our database (29 total). Also adaptable: T-mount (T2), Canon EF, M42 screw mount, Deckel (DKL), Tamron Adaptall, M39 / LTM (Leica thread).
- Canon EF-S 18-135mm f/3.5-5.6 IS 18–135 mm
- Canon EF-S 18-135mm f/3.5-5.6 IS STM 18–135 mm
- Canon EF-S 55-250mm f/4-5.6 IS STM 55–250 mm
- Canon EF-S 60mm f/2.8 Macro USM 60 mm
- Canon EF 75-300mm F4-5.6 III 75–300 mm
- Canon EF-S 10-18mm f/4.5-5.6 IS STM 10–18 mm
- Canon EF-S 10-22mm f/3.5-4.5 USM 10–22 mm
- Sigma 10-20mm f/3.5 EX DC HSM 10–20 mm
- Tokina atx-i 11-16mm F2.8 CF 11–16 mm
- Canon EF-S 15-85mm f/3.5-5.6 IS USM 15–85 mm
- Canon EF-S 17-55mm f/2.8 IS USM 17–55 mm
- Canon EF-S 17-85mm f/4-5.6 IS USM 17–85 mm
- Canon EF-S 18-135mm f/3.5-5.6 IS USM 18–135 mm
- Canon EF-S 18-200mm f/3.5-5.6 IS 18–200 mm
- Canon EF-S 18-55mm f/3.5-5.6 18–55 mm
- Canon EF-S 18-55mm f/3.5-5.6 II 18–55 mm
- Canon EF-S 18-55mm f/3.5-5.6 III 18–55 mm
- Canon EF-S 18-55mm f/3.5-5.6 IS 18–55 mm
- Canon EF-S 18-55mm f/3.5-5.6 IS II 18–55 mm
- Canon EF-S 18-55mm f/3.5-5.6 IS STM 18–55 mm
- Canon EF-S 18-55mm f/4-5.6 IS STM 18–55 mm
- Sigma 18-200mm f/3.5-6.3 DC Macro OS HSM 18–200 mm
- Canon EF-S 24mm f/2.8 STM 24 mm
- Samyang 35mm f/1.4 AS UMC 35 mm
- Canon EF-S 55-250mm f/4-5.6 IS 55–250 mm
- Canon EF-S 55-250mm f/4-5.6 IS II 55–250 mm
- Sigma 60-600mm F4.5-6.3 DG OS HSM | Sports 018 60–600 mm
- Sigma 60-600mm F4.5-6.3 DG OS HSM | Sports 018 + 1.4× ext. 60–600 mm
- Sigma 90mm f/2.8 Macro AF 90 mm
Frequently asked questions#
What is the crop factor of the Canon EOS 300D?
The Canon EOS 300D has a crop factor of 1.59× relative to 35 mm full frame (diagonal 27.3 mm vs 43.3 mm).
What size is the Canon EOS 300D sensor?
22.7 × 15.1 mm (APS-C (Canon)), an area of 343 mm² — 40% of full frame.
Is the Canon EOS 300D full frame?
No — its sensor is APS-C (Canon), which is 2.5× smaller in area than full frame.
How many megapixels does the Canon EOS 300D have?
6.3 megapixels (3,072 × 2,048 pixels), enough for a 10 × 7 inch print at 300 DPI.
What lens mount does the Canon EOS 300D use?
The Canon EOS 300D uses the Canon EF-S (flange distance 44.00 mm).
How long can I expose the night sky with the Canon EOS 300D?
With a 13 mm lens (21 mm equivalent) the 500 rule gives 24 s and the stricter NPF rule at f/2.8 gives 25 s.
