Canon SD1100 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Canon SD1100?

The Canon SD1100 has a crop factor of 6.02× relative to 35 mm full frame (diagonal 7.2 mm vs 43.3 mm).

6.02×

Crop factor

5.7×4.3 mm

Sensor size

25 mm²

Area · 3% of full frame

2008

Release year

Specifications#

Brand: Canon
Model: SD1100
Also known as: Canon DIGITAL IXUS 80 IS, Canon Digital IXUS 80 IS, Canon IXY DIGITAL 20 IS, Canon PowerShot SD1100 IS
Camera type: Compact
Released: 2008-03-01
Sensor size: 5.7 × 4.3 mm (1/2.5" sensor)
Crop factor: 6.02×

Specifications merged from Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Canon SD1100 sensor (highlighted) drawn to scale against common formats. Its area is 3% of a full-frame sensor, which collects about 5.1 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 6.02 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
4 mm	24 mm	71.3°	56.7°	83.8°
4.5 mm	27 mm	65.1°	51.3°	77.2°
5 mm	30 mm	59.7°	46.7°	71.4°
6 mm	36 mm	51.1°	39.6°	61.8°
8 mm	48 mm	39.5°	30.2°	48.4°
10 mm	60 mm	32.0°	24.4°	39.5°
12 mm	72 mm	26.9°	20.4°	33.3°
15 mm	90 mm	21.7°	16.4°	26.9°
20 mm	120 mm	16.3°	12.3°	20.4°
25 mm	151 mm	13.1°	9.9°	16.4°
30 mm	181 mm	10.9°	8.2°	13.7°
40 mm	241 mm	8.2°	6.2°	10.3°
50 mm	301 mm	6.6°	4.9°	8.2°
70 mm	422 mm	4.7°	3.5°	5.9°
100 mm	602 mm	3.3°	2.5°	4.1°
150 mm	903 mm	2.2°	1.7°	2.7°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 5.0 µm (the 0.030 mm full-frame standard scaled by the crop factor).

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
4 mm	f/2	34.1 cm	2.02 m	∞	∞	∞	∞	1.61 m
4 mm	f/2.8	53.2 cm	7.05 m	∞	∞	∞	∞	1.15 m
4 mm	f/4	99.9 cm	∞	∞	∞	∞	∞	80.7 cm
4 mm	f/8	∞	∞	∞	∞	∞	∞	40.6 cm
7 mm	f/2	10.1 cm	42.1 cm	1.94 m	5.80 m	∞	∞	4.93 m
7 mm	f/2.8	14.3 cm	61.4 cm	3.35 m	18.6 m	∞	∞	3.52 m
7 mm	f/4	20.9 cm	96.5 cm	9.44 m	∞	∞	∞	2.47 m
7 mm	f/8	47.8 cm	4.64 m	∞	∞	∞	∞	1.24 m
12 mm	f/2	3.4 cm	13.7 cm	56.1 cm	1.30 m	3.92 m	26.4 m	14.5 m
12 mm	f/2.8	4.7 cm	19.3 cm	80.0 cm	1.90 m	6.30 m	302 m	10.3 m
12 mm	f/4	6.8 cm	27.9 cm	1.19 m	2.99 m	13.2 m	∞	7.24 m
12 mm	f/8	13.8 cm	59.1 cm	3.16 m	15.7 m	∞	∞	3.63 m
20 mm	f/2	1.2 cm	4.9 cm	19.8 cm	44.8 cm	1.26 m	5.30 m	40.2 m
20 mm	f/2.8	1.7 cm	6.8 cm	27.7 cm	63.0 cm	1.79 m	7.92 m	28.7 m
20 mm	f/4	2.4 cm	9.8 cm	39.8 cm	91.1 cm	2.64 m	13.2 m	20.1 m
20 mm	f/8	4.8 cm	19.7 cm	82.1 cm	1.95 m	6.58 m	1.7 km	10.1 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 7 mm
f/1.2	f/7.2	8.20 m
f/1.4	f/8.4	7.03 m
f/1.8	f/10.8	5.47 m
f/2	f/12.0	4.93 m
f/2.8	f/16.9	3.52 m
f/4	f/24.1	2.47 m
f/5.6	f/33.7	1.76 m
f/8	f/48.2	1.24 m

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)

Focal length	500 rule
4 mm (24 mm eq.)	20.8 s
5 mm (30 mm eq.)	16.6 s
6 mm (36 mm eq.)	13.8 s
7 mm (42 mm eq.)	11.9 s
8 mm (48 mm eq.)	10.4 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
4 mm	1/25 s	0.3 s	1.3 s
8 mm	1/50 s	1/6 s	0.6 s
17 mm	1/100 s	1/13 s	0.3 s
33 mm	1/200 s	1/25 s	1/6 s

Lens#

The Canon SD1100 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 6.02.

Similar cameras#

Other 1/2.5" cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Canon SD1100?

The Canon SD1100 has a crop factor of 6.02× relative to 35 mm full frame (diagonal 7.2 mm vs 43.3 mm).

What size is the Canon SD1100 sensor?

5.7 × 4.3 mm (1/2.5"), an area of 25 mm² — 3% of full frame.

Is the Canon SD1100 full frame?

No — its sensor is 1/2.5", which is 34.8× smaller in area than full frame.

How long can I expose the night sky with the Canon SD1100?

With a 5 mm lens (30 mm equivalent) the 500 rule gives 17 s.
