Sony NEX-5 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Sony NEX-5?

The Sony NEX-5 has a crop factor of 1.54× relative to 35 mm full frame (diagonal 28.1 mm vs 43.3 mm).

1.54×

Crop factor

23.4×15.6 mm

Sensor size

365 mm²

Area · 42% of full frame

14.2 MP

Resolution

5.10 µm

Pixel pitch

f/7.6

Diffraction-limited aperture

2010

Release year

Specifications#

Brand: Sony
Model: NEX-5
Also known as: Sony Alpha NEX-5
Camera type: Mirrorless
Released: 2010-01-01
Lens mount: Sony E-mount
Sensor size: 23.4 × 15.6 mm (APS-C)
Crop factor: 1.54×
Resolution: 14.2 MP (4,592 × 3,056 px)
Continuous shooting: 2.3 fps
Weight: 287 g (10.1 oz)
Sensor: 23.4 × 15.6 mm Exmor APS-C HD CMOS Sensor
Storage: Memory Stick Pro Duo, Pro-HG Duo, SD, SDHC, SDXC
Viewfinder: Optional external optical viewfinder
Metering: Multi-segment, Center-weighted, Spot
Exposure modes: Intelligent Auto, Program, Aperture priority, Shutter priority, Manual, Scene modes
Flash: External flash (bundled)
Battery: NP-FW50, InfoLITHIUM, 7.2 V, 1080 mAh, 7.7 Wh, Lithium-Ion rechargeable battery
Dimensions: 111 mm × 59 mm × 38 mm
Lens: Sony E-mount
Launch price: $649.99 (with 16mm f2.8 lens) $699.99 (with 18-55mm 3.5-5.6 lens)
Drive: 2.3 frame/s, 7 frame/s in speed priority mode

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Sony NEX-5 sensor (highlighted) drawn to scale against common formats. Its area is 42% of a full-frame sensor, which collects about 1.2 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.54 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	12 mm	111.3°	88.5°	120.7°
10 mm	15 mm	99.0°	75.9°	109.2°
12 mm	18 mm	88.5°	66.0°	99.0°
14 mm	22 mm	79.8°	58.2°	90.3°
16 mm	25 mm	72.4°	52.0°	82.6°
18 mm	28 mm	66.0°	46.9°	76.0°
20 mm	31 mm	60.7°	42.6°	70.2°
24 mm	37 mm	52.0°	36.0°	60.7°
28 mm	43 mm	45.4°	31.1°	53.3°
35 mm	54 mm	37.0°	25.1°	43.8°
40 mm	62 mm	32.6°	22.1°	38.7°
50 mm	77 mm	26.3°	17.7°	31.4°
56 mm	86 mm	23.6°	15.9°	28.2°
70 mm	108 mm	19.0°	12.7°	22.7°
85 mm	131 mm	15.7°	10.5°	18.8°
100 mm	154 mm	13.3°	8.9°	16.0°
135 mm	208 mm	9.9°	6.6°	11.9°
200 mm	308 mm	6.7°	4.5°	8.0°
300 mm	462 mm	4.5°	3.0°	5.4°
400 mm	615 mm	3.4°	2.2°	4.0°
600 mm	923 mm	2.2°	1.5°	2.7°
800 mm	1231 mm	1.7°	1.1°	2.0°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 19.5 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
14 mm	f/1.8	8.8 cm	36.5 cm	1.63 m	4.49 m	44.0 m	∞	5.60 m
14 mm	f/2.8	13.8 cm	59.4 cm	3.19 m	16.2 m	∞	∞	3.60 m
14 mm	f/4	20.1 cm	92.8 cm	8.42 m	∞	∞	∞	2.53 m
14 mm	f/8	45.5 cm	4.09 m	∞	∞	∞	∞	1.27 m
28 mm	f/1.8	2.1 cm	8.7 cm	35.6 cm	81.3 cm	2.34 m	11.2 m	22.4 m
28 mm	f/2.8	3.3 cm	13.6 cm	56.0 cm	1.30 m	3.93 m	26.8 m	14.4 m
28 mm	f/4	4.7 cm	19.5 cm	81.6 cm	1.94 m	6.55 m	1.3 km	10.1 m
28 mm	f/8	9.5 cm	40.2 cm	1.86 m	5.46 m	466 m	∞	5.05 m
48 mm	f/1.8	0.7 cm	2.9 cm	11.9 cm	27.0 cm	75.9 cm	3.10 m	65.7 m
48 mm	f/2.8	1.1 cm	4.5 cm	18.5 cm	42.2 cm	1.19 m	4.99 m	42.2 m
48 mm	f/4	1.5 cm	6.5 cm	26.5 cm	60.6 cm	1.72 m	7.60 m	29.6 m
48 mm	f/8	3.1 cm	12.9 cm	53.8 cm	1.25 m	3.78 m	24.7 m	14.8 m
78 mm	f/1.8	0.2 cm	1.1 cm	4.4 cm	10.1 cm	28.4 cm	1.15 m	173 m
78 mm	f/2.8	0.4 cm	1.7 cm	6.9 cm	15.7 cm	44.3 cm	1.80 m	112 m
78 mm	f/4	0.5 cm	2.4 cm	9.9 cm	22.5 cm	63.4 cm	2.59 m	78.1 m
78 mm	f/8	1.1 cm	4.7 cm	19.8 cm	45.2 cm	1.28 m	5.44 m	39.1 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 28 mm
f/1.2	f/1.8	33.5 m
f/1.4	f/2.2	28.7 m
f/1.8	f/2.8	22.4 m
f/2	f/3.1	20.1 m
f/2.8	f/4.3	14.4 m
f/4	f/6.2	10.1 m
f/5.6	f/8.6	7.21 m
f/8	f/12.3	5.05 m

Diffraction & pixel pitch#

With 5.10 µm pixels, diffraction starts to soften pixel-level detail around f/7.6. For maximum sharpness keep landscapes between f/4.2 and f/8; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	0.7 px	sharp
f/4	5.4 µm	1.1 px	sharp
f/5.6	7.5 µm	1.5 px	sharp
f/8	10.7 µm	2.1 px	slight softening
f/11	14.8 µm	2.9 px	slight softening
f/16	21.5 µm	4.2 px	visibly soft
f/22	29.5 µm	5.8 px	visibly soft

Maximum print sizes#

At 14.2 MP the Sony NEX-5 produces 4,592 × 3,056 pixel images. See the 14 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	15.3 × 10.2 in	39 × 26 cm
240 DPI	Fine-art inkjet	19.1 × 12.7 in	49 × 32 cm
200 DPI	Wall print	23.0 × 15.3 in	58 × 39 cm
150 DPI	Poster, viewed from 1 m+	30.6 × 20.4 in	78 × 52 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
9 mm (14 mm eq.)	36.1 s	24.0 s	27.9 s	32.5 s
13 mm (20 mm eq.)	25.0 s	16.6 s	19.3 s	22.5 s
16 mm (25 mm eq.)	20.3 s	13.5 s	15.7 s	18.3 s
23 mm (35 mm eq.)	14.1 s	9.4 s	10.9 s	12.7 s
32 mm (49 mm eq.)	10.2 s	6.7 s	7.8 s	9.2 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
16 mm	1/25 s	0.3 s	1.3 s
32 mm	1/50 s	1/6 s	0.6 s
65 mm	1/100 s	1/13 s	0.3 s
130 mm	1/200 s	1/25 s	1/6 s

Lenses for the Sony NEX-5#

Native Sony E-mount lenses in our database (174 total). Also adaptable: T-mount (T2), M39 / LTM (Leica thread), M42 screw mount, Deckel (DKL).

Sony FE 12-24mm f/4 G 12–24 mm
Sony FE 20-70mm f/4 G 20–70 mm
Sony FE 20mm f/1.8 G 20 mm
Sony FE 24-105mm f/4 G OSS 24–105 mm
Sony FE 28-60mm f/4-5.6 28–60 mm
Sony FE 28-70mm f/3.5-5.6 OSS 28–70 mm
Sony FE 50mm f/1.2 GM 50 mm
Sony FE 70-200mm f/2.8 GM OSS 70–200 mm
Sony FE 70-200mm f/4 G OSS 70–200 mm
Sony FE 70-300mm f/4.5-5.6 G OSS 70–300 mm
Sony FE 85mm f/1.4 GM 85 mm
Sony FE 85mm f/1.8 85 mm
Sony FE 90mm f/2.8 Macro G OSS 90 mm
Sony FE 200-600mm f/5.6-6.3 G OSS 200–600 mm
Samyang 8mm f/2.8 UMC Fish-eye 8 mm
Samyang 8mm f/3.5 Fish-Eye CS 8 mm
Laowa 9mm f/2.8 Zero-D 9 mm
Laowa 9mm f/5.6 FF RL 9 mm
Viltrox AF 9mm f/2.8 Z/E/XF 9 mm
Laowa 10mm f/2.8 Zero-D FF 10 mm
Samyang 10mm f/2.8 ED AS NCS CS 10 mm
Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
Sony E 10-18mm f/4 OSS 10–18 mm
Voigtländer Heliar-Hyper Wide 10mm F5.6 10 mm
Sony E 11mm f/1.8 11 mm
Tamron 11-20mm f/2.8 Di III-A RXD (B060) 11–20 mm
Laowa 12mm f/2.8 Zero-D 12 mm
Samyang 12mm f/2.0 NCS CS 12 mm
Samyang 12mm f/2.8 Fish-Eye ED AS NCS 12 mm
Samyang AF 12mm f/2.0 12 mm
Zeiss Touit 2.8/12 12 mm
Viltrox AF 13mm F1.4 13 mm
Samyang 14mm f/2.8 AE ED AS IF UMC 14 mm
Samyang AF 14mm f/2.8 14 mm
Sigma 14-24mm F2.8 DG DN | Art 019 14–24 mm
Sigma 14mm f/1.8 DG HSM | A 14 mm

Similar cameras#

Other APS-C cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Sony NEX-5?

The Sony NEX-5 has a crop factor of 1.54× relative to 35 mm full frame (diagonal 28.1 mm vs 43.3 mm).

What size is the Sony NEX-5 sensor?

23.4 × 15.6 mm (APS-C), an area of 365 mm² — 42% of full frame.

Is the Sony NEX-5 full frame?

No — its sensor is APS-C, which is 2.4× smaller in area than full frame.

How many megapixels does the Sony NEX-5 have?

14.2 megapixels (4,592 × 3,056 pixels), enough for a 15 × 10 inch print at 300 DPI.

What lens mount does the Sony NEX-5 use?

The Sony NEX-5 uses the Sony E-mount (flange distance 18.00 mm).

How long can I expose the night sky with the Sony NEX-5?

With a 13 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 19 s.
