Samsung Galaxy NX Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Samsung Galaxy NX?

The Samsung Galaxy NX has a crop factor of 1.53× relative to 35 mm full frame (diagonal 28.3 mm vs 43.3 mm).

1.53×

Crop factor

23.5×15.7 mm

Sensor size

369 mm²

Area · 43% of full frame

20.3 MP

Resolution

4.26 µm

Pixel pitch

f/6.4

Diffraction-limited aperture

2013

Release year

Specifications#

Brand: Samsung
Model: Galaxy NX
Also known as: EK-GN120, Samsung EK-GN120
Camera type: Mirrorless
Released: 2013
Lens mount: Samsung NX
Sensor size: 23.5 × 15.7 mm (APS-C)
Crop factor: 1.53×
Resolution: 20.3 MP (5,513 × 3,682 px)
ISO range: 100 – 3,200
Continuous shooting: 8 fps
Weight: 495 g (17.5 oz)
Sensor: 20.3 megapixel APS-C CMOS image sensor
Storage: 16 GB, expanded via micro-SD/SDHC/SDXC up to 64 GB
Viewfinder: EVF color display, 100% field of view, 0.68x (35 mm equiv), 1.04x magnification, with 1.44M dots equivalent; and 640k dots Pentile AMOLED OCR articulated multi-angle 3 in color display
AF points / area: Contrast-detect 1 point AF (free selection), 15-area-focusing (normal) / 35-area-focusing (close up), face detection (max. 10 faces)
Metering: 221-segment TTL
Shutter: Electronically controlled vertical-run focal plane shutter
Flash: Built-in pop-up flash, 11 Guide Number at ISO 100
Battery: 4360 mAh
Dimensions: 136.5 mm x 101.46 mm x 56 mm
Lens: Interchangeable (Samsung NX-mount)
Drive: 8 fps up to 11 JPEG or 8 RAW frames, 3 fps up to 15 frames (JPEG)

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Samsung Galaxy NX sensor (highlighted) drawn to scale against common formats. Its area is 43% of a full-frame sensor, which collects about 1.2 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.53 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	12 mm	111.5°	88.9°	121.0°
10 mm	15 mm	99.2°	76.3°	109.4°
12 mm	18 mm	88.8°	66.4°	99.3°
14 mm	21 mm	80.0°	58.6°	90.5°
16 mm	24 mm	72.6°	52.3°	82.9°
18 mm	28 mm	66.3°	47.1°	76.3°
20 mm	31 mm	60.9°	42.9°	70.5°
24 mm	37 mm	52.2°	36.2°	61.0°
28 mm	43 mm	45.5°	31.3°	53.6°
35 mm	54 mm	37.1°	25.3°	44.0°
40 mm	61 mm	32.7°	22.2°	38.9°
50 mm	77 mm	26.4°	17.8°	31.6°
56 mm	86 mm	23.7°	16.0°	28.3°
70 mm	107 mm	19.1°	12.8°	22.8°
85 mm	130 mm	15.7°	10.6°	18.9°
100 mm	153 mm	13.4°	9.0°	16.1°
135 mm	207 mm	9.9°	6.7°	12.0°
200 mm	306 mm	6.7°	4.5°	8.1°
300 mm	459 mm	4.5°	3.0°	5.4°
400 mm	612 mm	3.4°	2.2°	4.0°
600 mm	919 mm	2.2°	1.5°	2.7°
800 mm	1225 mm	1.7°	1.1°	2.0°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 19.6 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
14 mm	f/1.8	8.8 cm	36.6 cm	1.64 m	4.53 m	46.1 m	∞	5.57 m
14 mm	f/2.8	13.9 cm	59.8 cm	3.22 m	16.6 m	∞	∞	3.59 m
14 mm	f/4	20.2 cm	93.4 cm	8.61 m	∞	∞	∞	2.51 m
14 mm	f/8	45.8 cm	4.17 m	∞	∞	∞	∞	1.26 m
28 mm	f/1.8	2.1 cm	8.8 cm	35.8 cm	81.7 cm	2.35 m	11.2 m	22.3 m
28 mm	f/2.8	3.3 cm	13.7 cm	56.3 cm	1.30 m	3.96 m	27.2 m	14.3 m
28 mm	f/4	4.7 cm	19.6 cm	82.1 cm	1.96 m	6.60 m	3.3 km	10.0 m
28 mm	f/8	9.5 cm	40.4 cm	1.87 m	5.51 m	860 m	∞	5.03 m
48 mm	f/1.8	0.7 cm	2.9 cm	12.0 cm	27.2 cm	76.3 cm	3.12 m	65.4 m
48 mm	f/2.8	1.1 cm	4.5 cm	18.6 cm	42.4 cm	1.20 m	5.02 m	42.0 m
48 mm	f/4	1.5 cm	6.5 cm	26.7 cm	60.9 cm	1.73 m	7.65 m	29.4 m
48 mm	f/8	3.1 cm	13.0 cm	54.1 cm	1.26 m	3.80 m	25.0 m	14.7 m
78 mm	f/1.8	0.2 cm	1.1 cm	4.5 cm	10.2 cm	28.6 cm	1.15 m	173 m
78 mm	f/2.8	0.4 cm	1.7 cm	6.9 cm	15.8 cm	44.5 cm	1.80 m	111 m
78 mm	f/4	0.5 cm	2.4 cm	9.9 cm	22.6 cm	63.7 cm	2.60 m	77.7 m
78 mm	f/8	1.1 cm	4.8 cm	19.9 cm	45.4 cm	1.29 m	5.47 m	38.9 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 28 mm
f/1.2	f/1.8	33.4 m
f/1.4	f/2.1	28.6 m
f/1.8	f/2.8	22.3 m
f/2	f/3.1	20.0 m
f/2.8	f/4.3	14.3 m
f/4	f/6.1	10.0 m
f/5.6	f/8.6	7.17 m
f/8	f/12.2	5.03 m

Diffraction & pixel pitch#

With 4.26 µm pixels, diffraction starts to soften pixel-level detail around f/6.4. For maximum sharpness keep landscapes between f/3.5 and f/6; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	0.9 px	sharp
f/4	5.4 µm	1.3 px	sharp
f/5.6	7.5 µm	1.8 px	sharp
f/8	10.7 µm	2.5 px	slight softening
f/11	14.8 µm	3.5 px	visibly soft
f/16	21.5 µm	5.0 px	visibly soft
f/22	29.5 µm	6.9 px	visibly soft

Maximum print sizes#

At 20.3 MP the Samsung Galaxy NX produces 5,513 × 3,682 pixel images. See the 20 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	18.4 × 12.3 in	47 × 31 cm
240 DPI	Fine-art inkjet	23.0 × 15.3 in	58 × 39 cm
200 DPI	Wall print	27.6 × 18.4 in	70 × 47 cm
150 DPI	Poster, viewed from 1 m+	36.8 × 24.5 in	93 × 62 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
9 mm (14 mm eq.)	36.3 s	21.2 s	25.1 s	29.8 s
13 mm (20 mm eq.)	25.1 s	14.7 s	17.4 s	20.6 s
16 mm (24 mm eq.)	20.4 s	11.9 s	14.1 s	16.7 s
23 mm (35 mm eq.)	14.2 s	8.3 s	9.8 s	11.6 s
33 mm (51 mm eq.)	9.9 s	5.8 s	6.8 s	8.1 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
16 mm	1/25 s	0.3 s	1.3 s
33 mm	1/50 s	1/6 s	0.6 s
65 mm	1/100 s	1/13 s	0.3 s
131 mm	1/200 s	1/25 s	1/6 s

Lenses for the Samsung Galaxy NX#

Native Samsung NX lenses in our database (10 total). Also adaptable: T-mount (T2), M39 / LTM (Leica thread), M42 screw mount, Deckel (DKL).

Samyang 8mm f/2.8 UMC Fish-eye 8 mm
Samyang 8mm f/3.5 Fish-Eye CS 8 mm
Samyang 10mm f/2.8 ED AS NCS CS 10 mm
Samyang 12mm f/2.0 NCS CS 12 mm
Samyang 14mm f/2.8 AE ED AS IF UMC 14 mm
Samyang 16mm f/2.0 ED AS UMC CS 16 mm
Samyang 20mm f/1.8 ED AS UMC 20 mm
Samyang 24mm f/1.4 ED AS IF UMC 24 mm
Samyang 85mm f/1.4 IF UMC Aspherical 85 mm
Samyang 135mm f/2 ED UMC 135 mm

Similar cameras#

Other APS-C cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Samsung Galaxy NX?

The Samsung Galaxy NX has a crop factor of 1.53× relative to 35 mm full frame (diagonal 28.3 mm vs 43.3 mm).

What size is the Samsung Galaxy NX sensor?

23.5 × 15.7 mm (APS-C), an area of 369 mm² — 43% of full frame.

Is the Samsung Galaxy NX full frame?

No — its sensor is APS-C, which is 2.3× smaller in area than full frame.

How many megapixels does the Samsung Galaxy NX have?

20.3 megapixels (5,513 × 3,682 pixels), enough for a 18 × 12 inch print at 300 DPI.

What lens mount does the Samsung Galaxy NX use?

The Samsung Galaxy NX uses the Samsung NX (flange distance 25.50 mm).

How long can I expose the night sky with the Samsung Galaxy NX?

With a 13 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 17 s.
