Specifications#
- Brand
- Ricoh
- Model
- GR (large sensor compact camera)
- Also known as
- GR, Ricoh GR
- Camera type
- Compact
- Sensor size
- 23.7 × 15.7 mm (APS-C)
- Crop factor
- 1.52×
- Resolution
- 16 MP (4,928 × 3,264 px)
- Fastest shutter
- 1/4,000 s
- Continuous shooting
- 4 fps
- Weight
- 245 g (8.6 oz)
- Sensor type
- CMOS
- Dimensions
- 117 x 61 x 34.7 mm (4.61 x 2.4 x 1.38 inches)
- Lens
- 28 mm equivalent
- Made in
- property linked P1071
- Drive
- 4 frames per second
Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.52 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 8 mm | 12 mm | 112.0° | 88.9° | 121.3° |
| 10 mm | 15 mm | 99.7° | 76.3° | 109.7° |
| 12 mm | 18 mm | 89.3° | 66.4° | 99.7° |
| 14 mm | 21 mm | 80.5° | 58.6° | 90.9° |
| 16 mm | 24 mm | 73.0° | 52.3° | 83.2° |
| 18 mm | 27 mm | 66.7° | 47.1° | 76.6° |
| 20 mm | 30 mm | 61.3° | 42.9° | 70.8° |
| 24 mm | 37 mm | 52.6° | 36.2° | 61.3° |
| 28 mm | 43 mm | 45.9° | 31.3° | 53.8° |
| 35 mm | 53 mm | 37.4° | 25.3° | 44.2° |
| 40 mm | 61 mm | 33.0° | 22.2° | 39.1° |
| 50 mm | 76 mm | 26.7° | 17.8° | 31.7° |
| 56 mm | 85 mm | 23.9° | 16.0° | 28.5° |
| 70 mm | 107 mm | 19.2° | 12.8° | 23.0° |
| 85 mm | 129 mm | 15.9° | 10.6° | 19.0° |
| 100 mm | 152 mm | 13.5° | 9.0° | 16.2° |
| 135 mm | 205 mm | 10.0° | 6.7° | 12.0° |
| 200 mm | 304 mm | 6.8° | 4.5° | 8.1° |
| 300 mm | 457 mm | 4.5° | 3.0° | 5.4° |
| 400 mm | 609 mm | 3.4° | 2.2° | 4.1° |
| 600 mm | 913 mm | 2.3° | 1.5° | 2.7° |
| 800 mm | 1218 mm | 1.7° | 1.1° | 2.0° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 19.7 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 14 mm | f/1.8 | 8.9 cm | 36.9 cm | 1.65 m | 4.58 m | 48.7 m | ∞ | 5.54 m |
| 14 mm | f/2.8 | 13.9 cm | 60.2 cm | 3.26 m | 17.2 m | ∞ | ∞ | 3.57 m |
| 14 mm | f/4 | 20.3 cm | 94.1 cm | 8.83 m | ∞ | ∞ | ∞ | 2.50 m |
| 14 mm | f/8 | 46.2 cm | 4.28 m | ∞ | ∞ | ∞ | ∞ | 1.26 m |
| 28 mm | f/1.8 | 2.1 cm | 8.8 cm | 36.0 cm | 82.2 cm | 2.37 m | 11.3 m | 22.1 m |
| 28 mm | f/2.8 | 3.3 cm | 13.7 cm | 56.6 cm | 1.31 m | 3.99 m | 27.7 m | 14.2 m |
| 28 mm | f/4 | 4.8 cm | 19.7 cm | 82.6 cm | 1.97 m | 6.67 m | ∞ | 9.97 m |
| 28 mm | f/8 | 9.6 cm | 40.7 cm | 1.88 m | 5.58 m | ∞ | ∞ | 5.00 m |
| 48 mm | f/1.8 | 0.7 cm | 2.9 cm | 12.0 cm | 27.3 cm | 76.7 cm | 3.14 m | 65.0 m |
| 48 mm | f/2.8 | 1.1 cm | 4.6 cm | 18.7 cm | 42.6 cm | 1.20 m | 5.06 m | 41.8 m |
| 48 mm | f/4 | 1.5 cm | 6.5 cm | 26.8 cm | 61.2 cm | 1.74 m | 7.71 m | 29.3 m |
| 48 mm | f/8 | 3.1 cm | 13.1 cm | 54.4 cm | 1.26 m | 3.83 m | 25.4 m | 14.7 m |
| 78 mm | f/1.8 | 0.2 cm | 1.1 cm | 4.5 cm | 10.2 cm | 28.7 cm | 1.16 m | 172 m |
| 78 mm | f/2.8 | 0.4 cm | 1.7 cm | 7.0 cm | 15.9 cm | 44.7 cm | 1.81 m | 110 m |
| 78 mm | f/4 | 0.5 cm | 2.4 cm | 10.0 cm | 22.8 cm | 64.0 cm | 2.61 m | 77.2 m |
| 78 mm | f/8 | 1.1 cm | 4.8 cm | 20.0 cm | 45.7 cm | 1.30 m | 5.51 m | 38.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 4.81 µm pixels, diffraction starts to soften pixel-level detail around f/7.2. For maximum sharpness keep landscapes between f/3.9 and f/7; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 0.8 px | sharp |
| f/4 | 5.4 µm | 1.1 px | sharp |
| f/5.6 | 7.5 µm | 1.6 px | sharp |
| f/8 | 10.7 µm | 2.2 px | slight softening |
| f/11 | 14.8 µm | 3.1 px | visibly soft |
| f/16 | 21.5 µm | 4.5 px | visibly soft |
| f/22 | 29.5 µm | 6.1 px | visibly soft |
Maximum print sizes#
At 16 MP the Ricoh GR (large sensor compact camera) produces 4,928 × 3,264 pixel images. See the 16 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 16.4 × 10.9 in | 42 × 28 cm |
| 240 DPI | Fine-art inkjet | 20.5 × 13.6 in | 52 × 35 cm |
| 200 DPI | Wall print | 24.6 × 16.3 in | 63 × 41 cm |
| 150 DPI | Poster, viewed from 1 m+ | 32.9 × 21.8 in | 83 × 55 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 9 mm (14 mm eq.) | 36.5 s | 23.0 s | 26.9 s | 31.6 s |
| 13 mm (20 mm eq.) | 25.3 s | 15.9 s | 18.6 s | 21.9 s |
| 16 mm (24 mm eq.) | 20.5 s | 13.0 s | 15.1 s | 17.8 s |
| 23 mm (35 mm eq.) | 14.3 s | 9.0 s | 10.5 s | 12.4 s |
| 33 mm (50 mm eq.) | 10.0 s | 6.3 s | 7.3 s | 8.6 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 16 mm | 1/25 s | 0.3 s | 1.3 s |
| 33 mm | 1/50 s | 1/6 s | 0.6 s |
| 66 mm | 1/100 s | 1/13 s | 0.3 s |
| 131 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Ricoh GR (large sensor compact camera) has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 1.52.
Similar cameras#
Other APS-C cameras from around the same time.
- Nikon D40 2006
- Pentax K110D 2006
- Nikon D60 2008
- Nikon D7000 2010
- Pentax K-5 2010
- Sony Alpha 65 2011
- Nikon D7100 2013
- Pentax K-3 2013
- Samsung Galaxy NX 2013
- Sony Alpha 58 2013
- Sony Alpha 77 II 2014
- Nikon D5600 2016
Frequently asked questions#
What is the crop factor of the Ricoh GR (large sensor compact camera)?
The Ricoh GR (large sensor compact camera) has a crop factor of 1.52× relative to 35 mm full frame (diagonal 28.4 mm vs 43.3 mm).
What size is the Ricoh GR (large sensor compact camera) sensor?
23.7 × 15.7 mm (APS-C), an area of 372 mm² — 43% of full frame.
Is the Ricoh GR (large sensor compact camera) full frame?
No — its sensor is APS-C, which is 2.3× smaller in area than full frame.
How many megapixels does the Ricoh GR (large sensor compact camera) have?
16 megapixels (4,928 × 3,264 pixels), enough for a 16 × 11 inch print at 300 DPI.
How long can I expose the night sky with the Ricoh GR (large sensor compact camera)?
With a 13 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 19 s.
