Panasonic Lumix DMC-GH1 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Panasonic Lumix DMC-GH1?

The Panasonic Lumix DMC-GH1 has a crop factor of 1.82× relative to 35 mm full frame (diagonal 23.8 mm vs 43.3 mm).

1.82×

Crop factor

18.9×14.5 mm

Sensor size

274 mm²

Area · 32% of full frame

14 MP

Resolution

4.72 µm

Pixel pitch

f/7.0

Diffraction-limited aperture

2009

Release year

Specifications#

Brand: Panasonic
Model: Lumix DMC-GH1
Also known as: DMC-GH1
Camera type: Mirrorless
Released: 2009-01-01
Lens mount: Micro Four Thirds
Sensor size: 18.9 × 14.5 mm (1.5" sensor)
Crop factor: 1.82×
Resolution: 14 MP (4,000 × 3,000 px)
ISO range: 100 – 3,200
Sensor: 18.89 × 14.48 mm Live MOS (17.3 x 13 usable in 4:3 aspect ratio)
Viewfinder: EVF color display, 100% field of view, 0.7x (35mm equiv), 1.4x magnification, with 1,440K dots equivalent; LCD or articulated multi-angle 3.0 inch color LCD (460,000 dots equivalent)
Metering: Intelligent Multiple (Center weighted, average and spot)
Exposure modes: Manual, Program, Automatic, Shutter Priority, Aperture Priority
Flash: Built-in pop up, TTL, GN 10.5m equivalent (ISO100 · m)
Lens: Micro Four Thirds System mount

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Panasonic Lumix DMC-GH1 sensor (highlighted) drawn to scale against common formats. Its area is 32% of a full-frame sensor, which collects about 1.7 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 1.82 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
8 mm	15 mm	99.5°	84.3°	112.2°
10 mm	18 mm	86.7°	71.8°	99.9°
12 mm	22 mm	76.4°	62.2°	89.5°
14 mm	25 mm	68.0°	54.7°	80.7°
16 mm	29 mm	61.1°	48.7°	73.3°
18 mm	33 mm	55.4°	43.8°	66.9°
20 mm	36 mm	50.6°	39.8°	61.5°
24 mm	44 mm	43.0°	33.6°	52.8°
28 mm	51 mm	37.3°	29.0°	46.1°
35 mm	64 mm	30.2°	23.4°	37.6°
40 mm	73 mm	26.6°	20.5°	33.1°
50 mm	91 mm	21.4°	16.5°	26.8°
56 mm	102 mm	19.1°	14.7°	24.0°
70 mm	127 mm	15.4°	11.8°	19.3°
85 mm	155 mm	12.7°	9.7°	15.9°
100 mm	182 mm	10.8°	8.3°	13.6°
135 mm	245 mm	8.0°	6.1°	10.1°
200 mm	364 mm	5.4°	4.1°	6.8°
300 mm	545 mm	3.6°	2.8°	4.5°
400 mm	727 mm	2.7°	2.1°	3.4°
600 mm	1091 mm	1.8°	1.4°	2.3°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 16.5 µm (the 0.030 mm full-frame standard scaled by the crop factor).

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
12 mm	f/1.8	10.2 cm	42.5 cm	1.97 m	5.96 m	∞	∞	4.86 m
12 mm	f/2.8	16.1 cm	70.5 cm	4.30 m	71.4 m	∞	∞	3.13 m
12 mm	f/4	23.5 cm	1.14 m	21.5 m	∞	∞	∞	2.19 m
12 mm	f/8	55.9 cm	10.1 m	∞	∞	∞	∞	1.10 m
24 mm	f/1.8	2.5 cm	10.1 cm	41.2 cm	94.3 cm	2.75 m	14.0 m	19.4 m
24 mm	f/2.8	3.8 cm	15.8 cm	65.0 cm	1.52 m	4.75 m	44.5 m	12.5 m
24 mm	f/4	5.5 cm	22.7 cm	95.5 cm	2.32 m	8.45 m	∞	8.75 m
24 mm	f/8	11.0 cm	47.1 cm	2.28 m	7.65 m	∞	∞	4.39 m
41 mm	f/1.8	0.8 cm	3.4 cm	13.9 cm	31.5 cm	88.3 cm	3.63 m	56.6 m
41 mm	f/2.8	1.3 cm	5.3 cm	21.6 cm	49.1 cm	1.39 m	5.92 m	36.4 m
41 mm	f/4	1.8 cm	7.5 cm	31.0 cm	70.7 cm	2.02 m	9.23 m	25.5 m
41 mm	f/8	3.6 cm	15.1 cm	63.0 cm	1.47 m	4.59 m	40.3 m	12.8 m
67 mm	f/1.8	0.3 cm	1.2 cm	5.1 cm	11.6 cm	32.7 cm	1.32 m	151 m
67 mm	f/2.8	0.4 cm	1.9 cm	8.0 cm	18.1 cm	50.9 cm	2.07 m	97.2 m
67 mm	f/4	0.6 cm	2.7 cm	11.4 cm	25.9 cm	72.9 cm	2.99 m	68.1 m
67 mm	f/8	1.3 cm	5.5 cm	22.8 cm	52.1 cm	1.48 m	6.39 m	34.1 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 24 mm
f/1.2	f/2.2	29.1 m
f/1.4	f/2.5	25.0 m
f/1.8	f/3.3	19.4 m
f/2	f/3.6	17.5 m
f/2.8	f/5.1	12.5 m
f/4	f/7.3	8.75 m
f/5.6	f/10.2	6.26 m
f/8	f/14.5	4.39 m

Diffraction & pixel pitch#

With 4.72 µm pixels, diffraction starts to soften pixel-level detail around f/7.0. For maximum sharpness keep landscapes between f/3.9 and f/7; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	0.8 px	sharp
f/4	5.4 µm	1.1 px	sharp
f/5.6	7.5 µm	1.6 px	sharp
f/8	10.7 µm	2.3 px	slight softening
f/11	14.8 µm	3.1 px	visibly soft
f/16	21.5 µm	4.5 px	visibly soft
f/22	29.5 µm	6.3 px	visibly soft

Maximum print sizes#

At 14 MP the Panasonic Lumix DMC-GH1 produces 4,000 × 3,000 pixel images. See the 14 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	13.3 × 10.0 in	34 × 25 cm
240 DPI	Fine-art inkjet	16.7 × 12.5 in	42 × 32 cm
200 DPI	Wall print	20.0 × 15.0 in	51 × 38 cm
150 DPI	Poster, viewed from 1 m+	26.7 × 20.0 in	68 × 51 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
8 mm (15 mm eq.)	34.4 s	25.6 s	30.0 s	35.2 s
11 mm (20 mm eq.)	25.0 s	18.6 s	21.8 s	25.6 s
13 mm (24 mm eq.)	21.2 s	15.7 s	18.4 s	21.7 s
19 mm (35 mm eq.)	14.5 s	10.8 s	12.6 s	14.8 s
28 mm (51 mm eq.)	9.8 s	7.3 s	8.6 s	10.1 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
13 mm	1/25 s	0.3 s	1.3 s
28 mm	1/50 s	1/6 s	0.6 s
55 mm	1/100 s	1/13 s	0.3 s
110 mm	1/200 s	1/25 s	1/6 s

Lenses for the Panasonic Lumix DMC-GH1#

Native Micro Four Thirds lenses in our database (100 total). Also adaptable: T-mount (T2), M39 / LTM (Leica thread), M42 screw mount, Deckel (DKL).

Olympus M.Zuiko Digital ED 7-14mm f/2.8 Pro 7–14 mm
Panasonic G Vario 7-14mm f/4.0 Asph. 7–14 mm
Laowa 7.5mm f/2.0 7.5 mm
Samyang 7.5mm f/3.5 UMC Fish-eye MFT 7.5 mm
Olympus M.Zuiko Digital ED 8-25mm f/4.0 PRO 8–25 mm
Olympus M.Zuiko Digital ED 8mm f/1.8 Fisheye Pro 8 mm
Panasonic Leica DG Vario-Elmarit 8-18mm f/2.8-4 Asph. 8–18 mm
Samyang 8mm f/3.5 Fish-Eye CS 8 mm
Laowa 9mm f/2.8 Zero-D 9 mm
Olympus M.Zuiko Digital ED 9-18mm f/4.0-5.6 9–18 mm
Panasonic Leica DG Summilux 9mm f/1.7 Asph. 9 mm
Panasonic Leica DG Vario-Summilux 10-25mm f/1.7 Asph. 10–25 mm
Samyang 10mm f/2.8 ED AS NCS CS 10 mm
OM System 12-100mm F4.0 12–100 mm
OM System 12-45mm F4.0 12–45 mm
Olympus M.Zuiko Digital ED 12-100mm f/4.0 IS Pro 12–100 mm
Olympus M.Zuiko Digital ED 12-200mm f/3.5-6.3 12–200 mm
Olympus M.Zuiko Digital ED 12-40mm f/2.8 Pro 12–40 mm
Olympus M.Zuiko Digital ED 12-45mm f/4.0 Pro 12–45 mm
Olympus M.Zuiko Digital ED 12-50mm f/3.5-6.3 EZ 12–50 mm
Olympus M.Zuiko Digital ED 12mm f/2.0 12 mm
Panasonic G Vario 12-32mm f/3.5-5.6 Asph. Mega OIS 12–32 mm
Panasonic G Vario 12-60mm f/3.5-5.6 Asph. Power OIS 12–60 mm
Panasonic G X Vario 12-35mm f/2.8 Asph. Power OIS 12–35 mm
Panasonic G X Vario 12-35mm f/2.8 II Asph. Power OIS 12–35 mm
Panasonic Leica DG Vario-Elmarit 12-60mm f/2.8-4.0 Asph. Power OIS 12–60 mm
Samyang 12mm f/2.0 NCS CS 12 mm
Olympus M.Zuiko Digital 14-42mm f/3.5-5.6 II 14–42 mm
Olympus M.Zuiko Digital ED 14-150mm f/4.0-5.6 14–150 mm
Olympus M.Zuiko Digital ED 14-150mm f/4.0-5.6 II 14–150 mm
Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 14–42 mm
Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ 14–42 mm
Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 II R 14–42 mm
Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 L 14–42 mm
Panasonic G 14mm f/2.5 Asph. 14 mm
Panasonic G 14mm f/2.5 Asph. + GWC1 0.79× 14 mm

Similar cameras#

Other 1.5" cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Panasonic Lumix DMC-GH1?

The Panasonic Lumix DMC-GH1 has a crop factor of 1.82× relative to 35 mm full frame (diagonal 23.8 mm vs 43.3 mm).

What size is the Panasonic Lumix DMC-GH1 sensor?

18.9 × 14.5 mm (1.5"), an area of 274 mm² — 32% of full frame.

Is the Panasonic Lumix DMC-GH1 full frame?

No — its sensor is 1.5", which is 3.2× smaller in area than full frame.

How many megapixels does the Panasonic Lumix DMC-GH1 have?

14 megapixels (4,000 × 3,000 pixels), enough for a 13 × 10 inch print at 300 DPI.

What lens mount does the Panasonic Lumix DMC-GH1 use?

The Panasonic Lumix DMC-GH1 uses the Micro Four Thirds (flange distance 19.25 mm).

How long can I expose the night sky with the Panasonic Lumix DMC-GH1?

With a 11 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 22 s.
