Specifications#
- Brand
- Panasonic
- Model
- Lumix DC-S1M2
- Also known as
- DC-S1M2, Panasonic LUMIX S1 II
- Camera type
- Mirrorless
- Released
- 2025-05-13
- Lens mount
- L-Mount
- Sensor size
- 35.6 × 23.8 mm (Full frame (35 mm))
- Crop factor
- 1.01×
- Resolution
- 24.2 MP (6,000 × 4,000 px)
- ISO range
- 100 – 51,200
- Fastest shutter
- 1/8,000 s
- Continuous shooting
- 30 fps
- Max video resolution
- 6K
- Weight
- 800 g (28.2 oz)
- Sensor
- BSI-CMOS sensor
- Viewfinder
- Electronic viewfinder (OLED)
- AF points / area
- Phase Hybrid AF with multiple selectable AF points
- Metering
- Multi-pattern, Center-weighted, Spot
- Exposure modes
- TTL metering
- Shutter
- Mechanical focal-plane shutter and electronic shutter
- Flash
- Hot shoe
- Battery
- DMW-BLK22 Li-ion battery; USB-PD rechargeable
- Dimensions
- 148.9 *
- Lens
- L-Mount system
- Predecessor
- Panasonic Lumix DC-S1 series
- Made in
- PR China
- Launch price
- JPY 455,400
- Drive
- Up to 30 fps (electronic), lower with mechanical
- Video
- 6K (approx. 5952×3968) up to 30p 5.9K up to 60p 4K (3840×2160) up to 120p Full HD (1920×1080) up to 240p Internal 10-bit recording; high bitrate options depending on codec (All-Intra and LongGOP options available)
Specifications merged from Wikipedia, Wikidata and Lensfun. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 1.01 to get the full-frame field of view. Angles are for a rectilinear lens focused at infinity.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 10 mm | 10 mm | 121.3° | 99.9° | 129.9° |
| 12 mm | 12 mm | 112.0° | 89.5° | 121.5° |
| 14 mm | 14 mm | 103.6° | 80.7° | 113.6° |
| 16 mm | 16 mm | 96.1° | 73.3° | 106.5° |
| 18 mm | 18 mm | 89.4° | 66.9° | 99.9° |
| 20 mm | 20 mm | 83.3° | 61.5° | 93.9° |
| 24 mm | 24 mm | 73.1° | 52.7° | 83.5° |
| 28 mm | 28 mm | 64.9° | 46.1° | 74.8° |
| 35 mm | 35 mm | 53.9° | 37.6° | 62.9° |
| 40 mm | 40 mm | 48.0° | 33.1° | 56.3° |
| 50 mm | 51 mm | 39.2° | 26.8° | 46.4° |
| 56 mm | 57 mm | 35.3° | 24.0° | 41.8° |
| 70 mm | 71 mm | 28.5° | 19.3° | 34.0° |
| 85 mm | 86 mm | 23.7° | 15.9° | 28.3° |
| 100 mm | 101 mm | 20.2° | 13.6° | 24.2° |
| 135 mm | 136 mm | 15.0° | 10.1° | 18.0° |
| 200 mm | 202 mm | 10.2° | 6.8° | 12.2° |
| 300 mm | 303 mm | 6.8° | 4.5° | 8.2° |
| 400 mm | 404 mm | 5.1° | 3.4° | 6.1° |
| 600 mm | 606 mm | 3.4° | 2.3° | 4.1° |
| 800 mm | 808 mm | 2.5° | 1.7° | 3.1° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 29.7 µm (the 0.030 mm full-frame standard scaled by the crop factor). Detailed tables: 24 mm f/1.8, 24 mm f/2.8, 35 mm f/1.8, 35 mm f/2.8, 50 mm f/1.8, 50 mm f/2.8.
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 22 mm | f/1.8 | 5.3 cm | 21.9 cm | 91.7 cm | 2.21 m | 7.88 m | ∞ | 9.08 m |
| 22 mm | f/2.8 | 8.3 cm | 34.6 cm | 1.54 m | 4.16 m | 31.8 m | ∞ | 5.84 m |
| 22 mm | f/4 | 11.9 cm | 50.9 cm | 2.54 m | 9.41 m | ∞ | ∞ | 4.10 m |
| 22 mm | f/8 | 24.8 cm | 1.25 m | 67.4 m | ∞ | ∞ | ∞ | 2.06 m |
| 43 mm | f/1.8 | 1.3 cm | 5.5 cm | 22.7 cm | 51.7 cm | 1.46 m | 6.28 m | 34.6 m |
| 43 mm | f/2.8 | 2.1 cm | 8.6 cm | 35.5 cm | 81.2 cm | 2.35 m | 11.2 m | 22.3 m |
| 43 mm | f/4 | 2.9 cm | 12.3 cm | 51.1 cm | 1.18 m | 3.54 m | 21.6 m | 15.6 m |
| 43 mm | f/8 | 5.9 cm | 25.0 cm | 1.07 m | 2.66 m | 10.7 m | ∞ | 7.83 m |
| 73 mm | f/1.8 | 0.4 cm | 1.9 cm | 7.7 cm | 17.6 cm | 49.5 cm | 2.01 m | 99.8 m |
| 73 mm | f/2.8 | 0.7 cm | 2.9 cm | 12.0 cm | 27.5 cm | 77.3 cm | 3.17 m | 64.2 m |
| 73 mm | f/4 | 1.0 cm | 4.1 cm | 17.2 cm | 39.3 cm | 1.11 m | 4.65 m | 44.9 m |
| 73 mm | f/8 | 1.9 cm | 8.3 cm | 34.6 cm | 79.6 cm | 2.31 m | 11.0 m | 22.5 m |
| 120 mm | f/1.8 | 0.1 cm | 0.7 cm | 2.8 cm | 6.4 cm | 18.1 cm | 73.4 cm | 270 m |
| 120 mm | f/2.8 | 0.2 cm | 1.0 cm | 4.3 cm | 10.0 cm | 28.2 cm | 1.14 m | 173 m |
| 120 mm | f/4 | 0.3 cm | 1.5 cm | 6.2 cm | 14.3 cm | 40.3 cm | 1.64 m | 121 m |
| 120 mm | f/8 | 0.6 cm | 2.9 cm | 12.4 cm | 28.6 cm | 81.0 cm | 3.35 m | 60.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Diffraction & pixel pitch#
With 5.93 µm pixels, diffraction starts to soften pixel-level detail around f/8.8. For maximum sharpness keep landscapes between f/4.9 and f/9; stopping down further trades detail for depth of field.
| Aperture | Airy disk diameter | Spread over | At 100% view |
|---|---|---|---|
| f/2.8 | 3.8 µm | 0.6 px | sharp |
| f/4 | 5.4 µm | 0.9 px | sharp |
| f/5.6 | 7.5 µm | 1.3 px | sharp |
| f/8 | 10.7 µm | 1.8 px | sharp |
| f/11 | 14.8 µm | 2.5 px | slight softening |
| f/16 | 21.5 µm | 3.6 px | visibly soft |
| f/22 | 29.5 µm | 5.0 px | visibly soft |
Maximum print sizes#
At 24.2 MP the Panasonic Lumix DC-S1M2 produces 6,000 × 4,000 pixel images. See the 24 megapixel guide or the print size calculator.
| Resolution | Typical use | Inches | Centimetres |
|---|---|---|---|
| 300 DPI | Photo-lab quality | 20.0 × 13.3 in | 51 × 34 cm |
| 240 DPI | Fine-art inkjet | 25.0 × 16.7 in | 64 × 42 cm |
| 200 DPI | Wall print | 30.0 × 20.0 in | 76 × 51 cm |
| 150 DPI | Poster, viewed from 1 m+ | 40.0 × 26.7 in | 102 × 68 cm |
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.
| Focal length | 500 rule | NPF f/1.8 | NPF f/2.8 | NPF f/4 |
|---|---|---|---|---|
| 14 mm (14 mm eq.) | 35.3 s | 17.2 s | 19.7 s | 22.7 s |
| 20 mm (20 mm eq.) | 24.7 s | 12.1 s | 13.8 s | 15.9 s |
| 24 mm (24 mm eq.) | 20.6 s | 10.0 s | 11.5 s | 13.2 s |
| 35 mm (35 mm eq.) | 14.1 s | 6.9 s | 7.9 s | 9.1 s |
| 49 mm (50 mm eq.) | 10.1 s | 4.9 s | 5.6 s | 6.5 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 24 mm | 1/25 s | 0.3 s | 1.3 s |
| 49 mm | 1/50 s | 1/6 s | 0.6 s |
| 99 mm | 1/100 s | 1/13 s | 0.3 s |
| 198 mm | 1/200 s | 1/25 s | 1/6 s |
Lenses for the Panasonic Lumix DC-S1M2#
Native L-Mount lenses in our database (55 total). Also adaptable: Leica M, T-mount (T2), M42 screw mount, Deckel (DKL), M39 / LTM (Leica thread).
- Laowa 9mm f/2.8 Zero-D 9 mm
- Laowa 9mm f/5.6 FF RL 9 mm
- Laowa 10mm f/2.8 Zero-D FF 10 mm
- Sigma 10-18mm F2.8 DC DN | Contemporary 023 10–18 mm
- Panasonic S 14-28mm f/4-5.6 Macro 14–28 mm
- Sigma 14-24mm F2.8 DG DN | Art 019 14–24 mm
- Laowa 15mm f/2.0 Zero-D 15 mm
- Panasonic S Pro 16-35mm f/4 16–35 mm
- Sigma 16-28mm F2.8 DG DN | Contemporary 022 16–28 mm
- Sigma 16-300mm F3.5-6.7 DC OS | C 16–300 mm
- Sigma 16mm f/1.4 DC DN Contemporary 16 mm
- Viltrox AF 16mm F1.8 FE/L/Z 16 mm
- Sigma 17mm F4 DG DN | Contemporary 023 17 mm
- Leica Elmarit-TL 1:2.8/18 Asph. 18 mm
- Panasonic S 18-40mm f/4.5-6.3 18–40 mm
- Sigma 18-50mm F2.8 DC DN | Contemporary 021 18–50 mm
- Panasonic S 20-60mm f/3.5-5.6 20–60 mm
- Sigma 20-200mm F3.5-6.3 DG | Contemporary 20–200 mm
- Sigma 20mm F2 DG DN | Contemporary 022 20 mm
- Leica Summicron-TL 1:2/23 Asph. 23 mm
- Viltrox AF 23mm F1.4 XF/Z/L 23 mm
- Leica Vario-Elmarit-SL 1:2.8-4/24-90 ASPH. 24–90 mm
- Leica Vario-Elmarit-SL 1:2.8/24-70 Asph. 24–70 mm
- Panasonic S 24-105mm f/4 Macro OIS 24–105 mm
- Panasonic S 24-60mm f/2.8 24–60 mm
- Panasonic S 24mm f/1.8 24 mm
- Sigma 24-70mm F2.8 DG DN II | Art 024 24–70 mm
- Sigma 24-70mm F2.8 DG DN | Art 019 24–70 mm
- Sigma 24mm F2 DG DN | Contemporary 021 24 mm
- Sigma 24mm F3.5 DG DN | Contemporary 021 24 mm
- Sigma 24mm f/1.4 DG HSM | A 24 mm
- Panasonic S 28–200mm f/4–7.1 Macro OIS 28–200 mm
- Sigma 28-70mm F2.8 DG DN | Contemporary 021 28–70 mm
- Sigma 28mm F1.4 DG HSM | Art 28 mm
- Sigma 30mm f/1.4 DC DN 30 mm
- Leica APO-Summicron-SL 1:2/35 Asph. 35 mm
Similar cameras#
Other Full frame (35 mm) cameras from around the same time.
- Canon EOS R6 Mark III 2025
- Nikon Z5II 2025
- Sony α7R VI 2026
- Canon EOS R5 Mark II 2024
- Nikon Z6III 2024
- Sony α1 II 2024
- Sony α9 III 2024
- Canon EOS R8 2023
- Nikon Z8 2023
- Nikon Zf 2023
- Sigma BF 2025
- Sony α7 V 2025
Frequently asked questions#
What is the crop factor of the Panasonic Lumix DC-S1M2?
The Panasonic Lumix DC-S1M2 has a crop factor of 1.01× relative to 35 mm full frame (diagonal 42.8 mm vs 43.3 mm).
What size is the Panasonic Lumix DC-S1M2 sensor?
35.6 × 23.8 mm (Full frame (35 mm)), an area of 847 mm² — 98% of full frame.
Is the Panasonic Lumix DC-S1M2 full frame?
Yes — its sensor is the same 36 × 24 mm size as 35 mm film.
How many megapixels does the Panasonic Lumix DC-S1M2 have?
24.2 megapixels (6,000 × 4,000 pixels), enough for a 20 × 13 inch print at 300 DPI.
What lens mount does the Panasonic Lumix DC-S1M2 use?
The Panasonic Lumix DC-S1M2 uses the L-Mount (flange distance 20.00 mm).
How long can I expose the night sky with the Panasonic Lumix DC-S1M2?
With a 20 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 14 s.
