Specifications#
- Brand
- Panon Shoko
- Model
- Widelux
- Camera type
- Large-sensor compact
- Sensor size
- 56.0 × 24.0 mm
- Crop factor
- 0.71×
- Fastest shutter
- 1/125 s
- Viewfinder
- Yes
- Metering
- No
- Exposure modes
- 1/15, 1/125, 1/250
- Flash
- No
- Lens
- 26mm pivoting lens
- Made in
- Japan
- Launch price
- About US$750 in 1988
Specifications merged from Wikipedia. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.71 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 15 mm | 106.3° | 59.5° | 110.8° |
| 23 mm | 16 mm | 101.2° | 55.1° | 105.9° |
| 28 mm | 20 mm | 90.0° | 46.4° | 94.8° |
| 32 mm | 23 mm | 82.4° | 41.1° | 87.2° |
| 35 mm | 25 mm | 77.3° | 37.8° | 82.1° |
| 45 mm | 32 mm | 63.8° | 29.9° | 68.2° |
| 55 mm | 39 mm | 54.0° | 24.6° | 58.0° |
| 63 mm | 45 mm | 47.9° | 21.6° | 51.6° |
| 80 mm | 57 mm | 38.6° | 17.1° | 41.7° |
| 90 mm | 64 mm | 34.6° | 15.2° | 37.4° |
| 110 mm | 78 mm | 28.6° | 12.5° | 31.0° |
| 120 mm | 85 mm | 26.3° | 11.4° | 28.5° |
| 150 mm | 107 mm | 21.1° | 9.1° | 23.0° |
| 180 mm | 128 mm | 17.7° | 7.6° | 19.2° |
| 250 mm | 178 mm | 12.8° | 5.5° | 13.9° |
| 350 mm | 249 mm | 9.1° | 3.9° | 9.9° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 42.2 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 30 mm | f/1.8 | 4.0 cm | 16.5 cm | 68.5 cm | 1.61 m | 5.10 m | 58.0 m | 11.9 m |
| 30 mm | f/2.8 | 6.2 cm | 25.9 cm | 1.11 m | 2.76 m | 11.4 m | ∞ | 7.64 m |
| 30 mm | f/4 | 8.9 cm | 37.7 cm | 1.71 m | 4.86 m | 72.2 m | ∞ | 5.36 m |
| 30 mm | f/8 | 18.2 cm | 84.0 cm | 6.54 m | ∞ | ∞ | ∞ | 2.69 m |
| 61 mm | f/1.8 | 0.9 cm | 3.8 cm | 15.9 cm | 36.2 cm | 1.02 m | 4.24 m | 49.0 m |
| 61 mm | f/2.8 | 1.4 cm | 6.0 cm | 24.7 cm | 56.5 cm | 1.61 m | 7.02 m | 31.5 m |
| 61 mm | f/4 | 2.0 cm | 8.5 cm | 35.5 cm | 81.5 cm | 2.36 m | 11.3 m | 22.1 m |
| 61 mm | f/8 | 4.0 cm | 17.2 cm | 72.7 cm | 1.72 m | 5.62 m | 97.5 m | 11.1 m |
| 104 mm | f/1.8 | 0.3 cm | 1.3 cm | 5.3 cm | 12.2 cm | 34.5 cm | 1.40 m | 142 m |
| 104 mm | f/2.8 | 0.4 cm | 2.0 cm | 8.3 cm | 19.0 cm | 53.7 cm | 2.19 m | 91.5 m |
| 104 mm | f/4 | 0.6 cm | 2.8 cm | 11.9 cm | 27.2 cm | 76.9 cm | 3.17 m | 64.1 m |
| 104 mm | f/8 | 1.2 cm | 5.6 cm | 23.8 cm | 54.7 cm | 1.57 m | 6.84 m | 32.1 m |
| 171 mm | f/1.8 | 0.1 cm | 0.4 cm | 1.9 cm | 4.4 cm | 12.6 cm | 51.2 cm | 385 m |
| 171 mm | f/2.8 | 0.1 cm | 0.7 cm | 3.0 cm | 6.9 cm | 19.5 cm | 79.6 cm | 247 m |
| 171 mm | f/4 | 0.2 cm | 1.0 cm | 4.2 cm | 9.8 cm | 27.9 cm | 1.14 m | 173 m |
| 171 mm | f/8 | 0.4 cm | 1.9 cm | 8.5 cm | 19.6 cm | 56.0 cm | 2.30 m | 86.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 20 mm (14 mm eq.) | 35.2 s |
| 28 mm (20 mm eq.) | 25.1 s |
| 34 mm (24 mm eq.) | 20.7 s |
| 49 mm (35 mm eq.) | 14.4 s |
| 70 mm (50 mm eq.) | 10.1 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 34 mm | 1/25 s | 0.3 s | 1.3 s |
| 70 mm | 1/50 s | 1/6 s | 0.6 s |
| 141 mm | 1/100 s | 1/13 s | 0.3 s |
| 282 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Panon Shoko Widelux has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 0.71.
Frequently asked questions#
What is the crop factor of the Panon Shoko Widelux?
The Panon Shoko Widelux has a crop factor of 0.71× relative to 35 mm full frame (diagonal 60.9 mm vs 43.3 mm).
What size is the Panon Shoko Widelux sensor?
56.0 × 24.0 mm (56.0 × 24.0 mm), an area of 1344 mm² — 156% of full frame.
Is the Panon Shoko Widelux full frame?
No — its sensor is larger than full frame (medium format).
How long can I expose the night sky with the Panon Shoko Widelux?
With a 28 mm lens (20 mm equivalent) the 500 rule gives 25 s.
