Specifications#
- Brand
- Olympus
- Model
- SP-560UZ
- Also known as
- Olympus SP-560 UltraZoom, SP-560 Ultra Zoom
- Camera type
- Compact
- Released
- 2007-01-01
- Sensor size
- 6.2 × 4.2 mm (1/2.3" sensor)
- Crop factor
- 5.80×
Specifications merged from Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Focal length equivalents & field of view#
Multiply any focal length by 5.80 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 4 mm | 23 mm | 75.2° | 55.5° | 86.0° |
| 4.5 mm | 26 mm | 68.8° | 50.1° | 79.3° |
| 5 mm | 29 mm | 63.3° | 45.7° | 73.5° |
| 6 mm | 35 mm | 54.3° | 38.7° | 63.7° |
| 8 mm | 46 mm | 42.1° | 29.5° | 50.0° |
| 10 mm | 58 mm | 34.2° | 23.8° | 40.9° |
| 12 mm | 70 mm | 28.8° | 19.9° | 34.5° |
| 15 mm | 87 mm | 23.2° | 16.0° | 27.9° |
| 20 mm | 116 mm | 17.5° | 12.0° | 21.1° |
| 25 mm | 145 mm | 14.0° | 9.6° | 17.0° |
| 30 mm | 174 mm | 11.7° | 8.0° | 14.2° |
| 40 mm | 232 mm | 8.8° | 6.0° | 10.7° |
| 50 mm | 290 mm | 7.0° | 4.8° | 8.5° |
| 70 mm | 406 mm | 5.0° | 3.4° | 6.1° |
| 100 mm | 580 mm | 3.5° | 2.4° | 4.3° |
| 150 mm | 870 mm | 2.4° | 1.6° | 2.8° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 5.2 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 4 mm | f/2 | 35.8 cm | 2.20 m | ∞ | ∞ | ∞ | ∞ | 1.55 m |
| 4 mm | f/2.8 | 56.2 cm | 9.65 m | ∞ | ∞ | ∞ | ∞ | 1.11 m |
| 4 mm | f/4 | 1.09 m | ∞ | ∞ | ∞ | ∞ | ∞ | 77.7 cm |
| 4 mm | f/8 | ∞ | ∞ | ∞ | ∞ | ∞ | ∞ | 39.1 cm |
| 7 mm | f/2 | 10.5 cm | 43.9 cm | 2.05 m | 6.31 m | ∞ | ∞ | 4.74 m |
| 7 mm | f/2.8 | 14.9 cm | 64.2 cm | 3.61 m | 24.5 m | ∞ | ∞ | 3.39 m |
| 7 mm | f/4 | 21.8 cm | 1.02 m | 11.5 m | ∞ | ∞ | ∞ | 2.37 m |
| 7 mm | f/8 | 50.4 cm | 5.66 m | ∞ | ∞ | ∞ | ∞ | 1.19 m |
| 12 mm | f/2 | 3.5 cm | 14.3 cm | 58.3 cm | 1.35 m | 4.11 m | 29.6 m | 13.9 m |
| 12 mm | f/2.8 | 4.9 cm | 20.1 cm | 83.3 cm | 1.98 m | 6.71 m | ∞ | 9.95 m |
| 12 mm | f/4 | 7.0 cm | 29.0 cm | 1.24 m | 3.16 m | 14.7 m | ∞ | 6.97 m |
| 12 mm | f/8 | 14.3 cm | 61.8 cm | 3.39 m | 19.6 m | ∞ | ∞ | 3.49 m |
| 20 mm | f/2 | 1.2 cm | 5.1 cm | 20.5 cm | 46.5 cm | 1.31 m | 5.53 m | 38.7 m |
| 20 mm | f/2.8 | 1.7 cm | 7.1 cm | 28.8 cm | 65.5 cm | 1.86 m | 8.31 m | 27.6 m |
| 20 mm | f/4 | 2.5 cm | 10.2 cm | 41.4 cm | 94.8 cm | 2.76 m | 14.1 m | 19.3 m |
| 20 mm | f/8 | 5.0 cm | 20.5 cm | 85.5 cm | 2.04 m | 7.02 m | ∞ | 9.68 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 4 mm (23 mm eq.) | 21.6 s |
| 5 mm (29 mm eq.) | 17.2 s |
| 6 mm (35 mm eq.) | 14.4 s |
| 7 mm (41 mm eq.) | 12.3 s |
| 9 mm (52 mm eq.) | 9.6 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 4 mm | 1/25 s | 0.3 s | 1.3 s |
| 9 mm | 1/50 s | 1/6 s | 0.6 s |
| 17 mm | 1/100 s | 1/13 s | 0.3 s |
| 34 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Olympus SP-560UZ has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 5.80.
Similar cameras#
Other 1/2.3" cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Olympus SP-560UZ?
The Olympus SP-560UZ has a crop factor of 5.80× relative to 35 mm full frame (diagonal 7.5 mm vs 43.3 mm).
What size is the Olympus SP-560UZ sensor?
6.2 × 4.2 mm (1/2.3"), an area of 26 mm² — 3% of full frame.
Is the Olympus SP-560UZ full frame?
No — its sensor is 1/2.3", which is 33.3× smaller in area than full frame.
How long can I expose the night sky with the Olympus SP-560UZ?
With a 5 mm lens (29 mm equivalent) the 500 rule gives 17 s.
