Specifications#
- Brand
- Mamiya
- Model
- C
- Camera type
- Twin-lens reflex
- Released
- 1956
- Film format
- 6 × 6 cm film
- Image area
- 56.0 × 56.0 mm (6 × 6 cm film)
- Crop factor
- 0.55×
- Sensor type
- Film
- Viewfinder
- ground glass, waist-level
- Metering
- in optional viewfinders or external
- Exposure modes
- manual
- Shutter
- in lens (leaf)
- Lens
- Interchangeable
- Predecessor
- Mamiyaflex
- Production
- 1956–1994
Specifications merged from Wikipedia. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.55 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 11 mm | 106.3° | 106.3° | 124.1° |
| 23 mm | 13 mm | 101.2° | 101.2° | 119.7° |
| 28 mm | 15 mm | 90.0° | 90.0° | 109.5° |
| 32 mm | 17 mm | 82.4° | 82.4° | 102.1° |
| 35 mm | 19 mm | 77.3° | 77.3° | 97.1° |
| 45 mm | 25 mm | 63.8° | 63.8° | 82.7° |
| 55 mm | 30 mm | 54.0° | 54.0° | 71.5° |
| 63 mm | 34 mm | 47.9° | 47.9° | 64.3° |
| 80 mm | 44 mm | 38.6° | 38.6° | 52.7° |
| 90 mm | 49 mm | 34.6° | 34.6° | 47.5° |
| 110 mm | 60 mm | 28.6° | 28.6° | 39.6° |
| 120 mm | 66 mm | 26.3° | 26.3° | 36.5° |
| 150 mm | 82 mm | 21.1° | 21.1° | 29.6° |
| 180 mm | 98 mm | 17.7° | 17.7° | 24.8° |
| 250 mm | 137 mm | 12.8° | 12.8° | 18.0° |
| 350 mm | 191 mm | 9.1° | 9.1° | 12.9° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 54.9 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 40 mm | f/1.8 | 2.8 cm | 11.9 cm | 49.2 cm | 1.14 m | 3.38 m | 19.8 m | 16.2 m |
| 40 mm | f/2.8 | 4.4 cm | 18.6 cm | 78.1 cm | 1.86 m | 6.17 m | 228 m | 10.4 m |
| 40 mm | f/4 | 6.3 cm | 26.8 cm | 1.16 m | 2.92 m | 12.7 m | ∞ | 7.32 m |
| 40 mm | f/8 | 12.8 cm | 56.7 cm | 3.03 m | 14.4 m | ∞ | ∞ | 3.68 m |
| 79 mm | f/1.8 | 0.7 cm | 2.9 cm | 12.2 cm | 27.8 cm | 78.4 cm | 3.22 m | 63.2 m |
| 79 mm | f/2.8 | 1.0 cm | 4.5 cm | 19.0 cm | 43.4 cm | 1.23 m | 5.20 m | 40.7 m |
| 79 mm | f/4 | 1.5 cm | 6.5 cm | 27.2 cm | 62.3 cm | 1.79 m | 7.95 m | 28.5 m |
| 79 mm | f/8 | 3.0 cm | 13.0 cm | 55.1 cm | 1.29 m | 3.94 m | 27.3 m | 14.3 m |
| 134 mm | f/1.8 | 0.2 cm | 1.0 cm | 4.1 cm | 9.5 cm | 26.8 cm | 1.09 m | 182 m |
| 134 mm | f/2.8 | 0.3 cm | 1.5 cm | 6.4 cm | 14.7 cm | 41.7 cm | 1.70 m | 117 m |
| 134 mm | f/4 | 0.4 cm | 2.1 cm | 9.1 cm | 21.1 cm | 59.7 cm | 2.45 m | 81.9 m |
| 134 mm | f/8 | 0.9 cm | 4.2 cm | 18.3 cm | 42.3 cm | 1.21 m | 5.13 m | 41.0 m |
| 221 mm | f/1.8 | 0.1 cm | 0.3 cm | 1.4 cm | 3.4 cm | 9.7 cm | 39.6 cm | 494 m |
| 221 mm | f/2.8 | 0.1 cm | 0.5 cm | 2.2 cm | 5.2 cm | 15.0 cm | 61.6 cm | 318 m |
| 221 mm | f/4 | 0.1 cm | 0.7 cm | 3.2 cm | 7.5 cm | 21.5 cm | 88.1 cm | 223 m |
| 221 mm | f/8 | 0.3 cm | 1.4 cm | 6.4 cm | 15.0 cm | 43.1 cm | 1.77 m | 111 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 26 mm (14 mm eq.) | 35.2 s |
| 37 mm (20 mm eq.) | 24.7 s |
| 44 mm (24 mm eq.) | 20.8 s |
| 64 mm (35 mm eq.) | 14.3 s |
| 92 mm (50 mm eq.) | 9.9 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 44 mm | 1/25 s | 0.3 s | 1.3 s |
| 92 mm | 1/50 s | 1/6 s | 0.6 s |
| 183 mm | 1/100 s | 1/13 s | 0.3 s |
| 366 mm | 1/200 s | 1/25 s | 1/6 s |
Film stocks for the Mamiya C#
Films currently made in 120 format.
- ADOX CHS 100 II ISO 100
- ADOX CMS 20 II PRO ISO 20
- ADOX HR-50 ISO 50
- Agfa Copex Rapid ISO 50
- Bergger Pancro 400 ISO 400
- CatLABS X FILM 100 Color ISO 100
- CatLABS X FILM 320 Pro ISO 320
- CatLABS X FILM 80 ISO 80
- CineStill 400D ISO 400
- CineStill 50D ISO 50
- CineStill 800T ISO 800
- CineStill Red Rum ISO 200
- CineStill bwXX ISO 250
- FILM Ferrania Orto ISO 50
- FILM Ferrania P30 ISO 80
- Film Photography Project Dracula ISO 64
- Film Photography Project Frankenstein ISO 200
- Film Photography Project THE MUMMY 400 ISO 400
Similar cameras#
Other 6 × 6 cm film film cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Mamiya C?
The Mamiya C has a crop factor of 0.55× relative to 35 mm full frame (diagonal 79.2 mm vs 43.3 mm).
What size is the Mamiya C frame?
56.0 × 56.0 mm (6 × 6 cm film), an area of 3136 mm² — 363% of full frame.
How long can I expose the night sky with the Mamiya C?
With a 37 mm lens (20 mm equivalent) the 500 rule gives 25 s.
