Specifications#
- Brand
- Konishiroku
- Model
- Konica FC-1
- Camera type
- Large-sensor compact
- Sensor size
- 45.0 × 40.0 mm (Medium format 44 × 33 mm)
- Crop factor
- 0.72×
- ISO range
- 25 – 1,600
- Weight
- 515 g (18.2 oz)
- Focus
- Manual
- Metering
- EV0 to EV19 @ ASA 100
- Exposure modes
- Shutter priority, manual
- Flash
- Hot shoe, PC socket
- Battery
- 4SR44 6 V battery
- Dimensions
- 89 × 140 × 45 mm
- Made in
- Japan
Specifications merged from Wikipedia. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.72 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 15 mm | 93.9° | 87.2° | 110.2° |
| 23 mm | 17 mm | 88.7° | 82.0° | 105.2° |
| 28 mm | 20 mm | 77.6° | 71.1° | 94.1° |
| 32 mm | 23 mm | 70.2° | 64.0° | 86.5° |
| 35 mm | 25 mm | 65.5° | 59.5° | 81.4° |
| 45 mm | 32 mm | 53.1° | 47.9° | 67.6° |
| 55 mm | 40 mm | 44.5° | 40.0° | 57.4° |
| 63 mm | 45 mm | 39.3° | 35.2° | 51.1° |
| 80 mm | 57 mm | 31.4° | 28.1° | 41.2° |
| 90 mm | 65 mm | 28.1° | 25.1° | 37.0° |
| 110 mm | 79 mm | 23.1° | 20.6° | 30.6° |
| 120 mm | 86 mm | 21.2° | 18.9° | 28.2° |
| 150 mm | 108 mm | 17.1° | 15.2° | 22.7° |
| 180 mm | 129 mm | 14.3° | 12.7° | 19.0° |
| 250 mm | 180 mm | 10.3° | 9.1° | 13.7° |
| 350 mm | 252 mm | 7.4° | 6.5° | 9.8° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 41.7 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 30 mm | f/1.8 | 3.9 cm | 16.3 cm | 67.6 cm | 1.59 m | 5.01 m | 54.2 m | 12.0 m |
| 30 mm | f/2.8 | 6.1 cm | 25.6 cm | 1.10 m | 2.72 m | 11.1 m | ∞ | 7.73 m |
| 30 mm | f/4 | 8.8 cm | 37.2 cm | 1.69 m | 4.75 m | 61.6 m | ∞ | 5.42 m |
| 30 mm | f/8 | 18.0 cm | 82.7 cm | 6.28 m | ∞ | ∞ | ∞ | 2.72 m |
| 60 mm | f/1.8 | 0.9 cm | 3.9 cm | 16.2 cm | 37.0 cm | 1.04 m | 4.34 m | 48.0 m |
| 60 mm | f/2.8 | 1.4 cm | 6.1 cm | 25.3 cm | 57.8 cm | 1.65 m | 7.21 m | 30.9 m |
| 60 mm | f/4 | 2.0 cm | 8.7 cm | 36.3 cm | 83.4 cm | 2.42 m | 11.7 m | 21.6 m |
| 60 mm | f/8 | 4.1 cm | 17.6 cm | 74.4 cm | 1.77 m | 5.80 m | 123 m | 10.8 m |
| 102 mm | f/1.8 | 0.3 cm | 1.3 cm | 5.5 cm | 12.6 cm | 35.4 cm | 1.44 m | 139 m |
| 102 mm | f/2.8 | 0.4 cm | 2.0 cm | 8.5 cm | 19.6 cm | 55.2 cm | 2.25 m | 89.1 m |
| 102 mm | f/4 | 0.6 cm | 2.9 cm | 12.2 cm | 28.0 cm | 79.1 cm | 3.26 m | 62.4 m |
| 102 mm | f/8 | 1.3 cm | 5.8 cm | 24.5 cm | 56.3 cm | 1.61 m | 7.07 m | 31.3 m |
| 168 mm | f/1.8 | 0.1 cm | 0.4 cm | 2.0 cm | 4.5 cm | 12.9 cm | 52.4 cm | 376 m |
| 168 mm | f/2.8 | 0.1 cm | 0.7 cm | 3.0 cm | 7.0 cm | 20.0 cm | 81.6 cm | 242 m |
| 168 mm | f/4 | 0.2 cm | 1.0 cm | 4.3 cm | 10.1 cm | 28.6 cm | 1.17 m | 169 m |
| 168 mm | f/8 | 0.4 cm | 2.0 cm | 8.7 cm | 20.1 cm | 57.4 cm | 2.36 m | 84.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 19 mm (14 mm eq.) | 36.6 s |
| 28 mm (20 mm eq.) | 24.8 s |
| 33 mm (24 mm eq.) | 21.1 s |
| 49 mm (35 mm eq.) | 14.2 s |
| 70 mm (50 mm eq.) | 9.9 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 33 mm | 1/25 s | 0.3 s | 1.3 s |
| 70 mm | 1/50 s | 1/6 s | 0.6 s |
| 139 mm | 1/100 s | 1/13 s | 0.3 s |
| 278 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Konishiroku Konica FC-1 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 0.72.
Similar cameras#
Other Medium format 44 × 33 mm cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Konishiroku Konica FC-1?
The Konishiroku Konica FC-1 has a crop factor of 0.72× relative to 35 mm full frame (diagonal 60.2 mm vs 43.3 mm).
What size is the Konishiroku Konica FC-1 sensor?
45.0 × 40.0 mm (Medium format 44 × 33 mm), an area of 1800 mm² — 208% of full frame.
Is the Konishiroku Konica FC-1 full frame?
No — its sensor is larger than full frame (medium format).
How long can I expose the night sky with the Konishiroku Konica FC-1?
With a 28 mm lens (20 mm equivalent) the 500 rule gives 25 s.
