Specifications#
- Brand
- Konica
- Model
- FT-1
- Camera type
- Film SLR
- Film format
- 135 film
- Image area
- 46.0 × 43.0 mm
- Crop factor
- 0.69×
- ISO range
- 25 – 3,200
- Weight
- 570 g (20.1 oz)
- Focus
- Manual
- Metering
- EV0.7 to EV19 @ ASA 100
- Exposure modes
- Shutter priority, manual
- Flash
- Hot shoe, PC socket
- Battery
- 4 AA or AAA
- Dimensions
- 91 × 143 × 46 mm
- Made in
- Japan
Specifications merged from Wikipedia and Wikidata. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.69 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 14 mm | 95.2° | 91.3° | 112.6° |
| 23 mm | 16 mm | 90.0° | 86.1° | 107.7° |
| 28 mm | 19 mm | 78.8° | 75.0° | 96.7° |
| 32 mm | 22 mm | 71.4° | 67.8° | 89.1° |
| 35 mm | 24 mm | 66.6° | 63.1° | 83.9° |
| 45 mm | 31 mm | 54.1° | 51.1° | 70.0° |
| 55 mm | 38 mm | 45.4° | 42.7° | 59.6° |
| 63 mm | 43 mm | 40.1° | 37.7° | 53.1° |
| 80 mm | 55 mm | 32.1° | 30.1° | 43.0° |
| 90 mm | 62 mm | 28.7° | 26.9° | 38.6° |
| 110 mm | 76 mm | 23.6° | 22.1° | 31.9° |
| 120 mm | 82 mm | 21.7° | 20.3° | 29.4° |
| 150 mm | 103 mm | 17.4° | 16.3° | 23.7° |
| 180 mm | 124 mm | 14.6° | 13.6° | 19.8° |
| 250 mm | 172 mm | 10.5° | 9.8° | 14.4° |
| 350 mm | 240 mm | 7.5° | 7.0° | 10.3° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 43.7 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 32 mm | f/1.8 | 3.6 cm | 14.9 cm | 61.8 cm | 1.44 m | 4.46 m | 36.9 m | 13.1 m |
| 32 mm | f/2.8 | 5.6 cm | 23.4 cm | 99.5 cm | 2.43 m | 9.15 m | ∞ | 8.41 m |
| 32 mm | f/4 | 8.0 cm | 33.9 cm | 1.51 m | 4.08 m | 30.0 m | ∞ | 5.90 m |
| 32 mm | f/8 | 16.4 cm | 74.1 cm | 4.89 m | ∞ | ∞ | ∞ | 2.96 m |
| 63 mm | f/1.8 | 0.9 cm | 3.7 cm | 15.4 cm | 35.0 cm | 98.7 cm | 4.09 m | 50.6 m |
| 63 mm | f/2.8 | 1.3 cm | 5.8 cm | 23.9 cm | 54.7 cm | 1.56 m | 6.75 m | 32.5 m |
| 63 mm | f/4 | 1.9 cm | 8.3 cm | 34.3 cm | 78.9 cm | 2.28 m | 10.8 m | 22.8 m |
| 63 mm | f/8 | 3.9 cm | 16.6 cm | 70.2 cm | 1.66 m | 5.36 m | 74.3 m | 11.4 m |
| 107 mm | f/1.8 | 0.3 cm | 1.2 cm | 5.2 cm | 11.9 cm | 33.6 cm | 1.36 m | 146 m |
| 107 mm | f/2.8 | 0.4 cm | 1.9 cm | 8.1 cm | 18.6 cm | 52.4 cm | 2.14 m | 93.8 m |
| 107 mm | f/4 | 0.6 cm | 2.7 cm | 11.6 cm | 26.5 cm | 75.1 cm | 3.09 m | 65.7 m |
| 107 mm | f/8 | 1.2 cm | 5.5 cm | 23.2 cm | 53.4 cm | 1.53 m | 6.64 m | 32.9 m |
| 176 mm | f/1.8 | 0.1 cm | 0.4 cm | 1.9 cm | 4.3 cm | 12.2 cm | 49.9 cm | 394 m |
| 176 mm | f/2.8 | 0.1 cm | 0.7 cm | 2.9 cm | 6.7 cm | 19.0 cm | 77.7 cm | 254 m |
| 176 mm | f/4 | 0.2 cm | 0.9 cm | 4.1 cm | 9.6 cm | 27.2 cm | 1.11 m | 178 m |
| 176 mm | f/8 | 0.4 cm | 1.9 cm | 8.2 cm | 19.1 cm | 54.6 cm | 2.24 m | 88.9 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 20 mm (14 mm eq.) | 36.4 s |
| 29 mm (20 mm eq.) | 25.1 s |
| 35 mm (24 mm eq.) | 20.8 s |
| 51 mm (35 mm eq.) | 14.3 s |
| 73 mm (50 mm eq.) | 10.0 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 35 mm | 1/25 s | 0.3 s | 1.3 s |
| 73 mm | 1/50 s | 1/6 s | 0.6 s |
| 146 mm | 1/100 s | 1/13 s | 0.3 s |
| 291 mm | 1/200 s | 1/25 s | 1/6 s |
Film stocks for the Konica FT-1#
Films currently made in 135 format.
- ADOX CHS 100 II ISO 100
- ADOX CMS 20 II PRO ISO 20
- ADOX Color Mission 200 ISO 200
- ADOX Color Mission Helios ISO 3
- ADOX HR-50 ISO 50
- ADOX Scala 50 ISO 50
- Agfa Copex Rapid ISO 50
- AgfaPhoto APX 100 ISO 100
- AgfaPhoto APX 200 ISO 200
- AgfaPhoto APX 400 ISO 400
- AgfaPhoto Color 400 ISO 400
- Argenti ARF+ Reporter Film Plus ISO 400
- Argenti Nanotomic X ISO 32
- Argenti Pan-X ISO 100
- Argenti Scale-X ISO 100
- Bergger Pancro 400 ISO 400
- CatLABS X FILM 320 ISO 320
- CatLABS X FILM 320 Pro ISO 320
Frequently asked questions#
What is the crop factor of the Konica FT-1?
The Konica FT-1 has a crop factor of 0.69× relative to 35 mm full frame (diagonal 63.0 mm vs 43.3 mm).
What size is the Konica FT-1 frame?
46.0 × 43.0 mm (135 film), an area of 1978 mm² — 229% of full frame.
How long can I expose the night sky with the Konica FT-1?
With a 29 mm lens (20 mm equivalent) the 500 rule gives 25 s.
