Fujifilm XQ1 Specs, Sensor Size & Crop Factor

Q: What is the crop factor of the Fujifilm XQ1?

The Fujifilm XQ1 has a crop factor of 3.93× relative to 35 mm full frame (diagonal 11.0 mm vs 43.3 mm).

3.93×

Crop factor

8.8×6.6 mm

Sensor size

58 mm²

Area · 7% of full frame

12 MP

Resolution

2.20 µm

Pixel pitch

f/3.3

Diffraction-limited aperture

Specifications#

Brand: Fujifilm
Model: XQ1
Camera type: Compact
Sensor size: 8.8 × 6.6 mm (2/3" sensor)
Crop factor: 3.93×
Resolution: 12 MP (4,000 × 3,000 px)
Fastest shutter: 1/4,000 s
Continuous shooting: 12 fps
Weight: 206 g (7.3 oz)
Sensor type: X-Trans CMOS II
Dimensions: 100 x 59 x 33 mm (3.94 x 2.32 x 1.3 inches)
Lens: 25-100 mm equivalent
Drive: 12 frames per second

Specifications merged from Wikipedia, Wikidata, Lensfun and openMVG. Spot an error? Tell us.

Sensor size compared#

The Fujifilm XQ1 sensor (highlighted) drawn to scale against common formats. Its area is 7% of a full-frame sensor, which collects about 3.9 stops less total light at the same exposure.

Focal length equivalents & field of view#

Multiply any focal length by 3.93 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.

Lens on this camera	Full-frame equivalent	Horizontal	Vertical	Diagonal
4 mm	16 mm	95.5°	79.0°	107.9°
4.5 mm	18 mm	88.7°	72.5°	101.4°
5 mm	20 mm	82.7°	66.8°	95.5°
6 mm	24 mm	72.5°	57.6°	85.0°
8 mm	31 mm	57.6°	44.8°	69.0°
10 mm	39 mm	47.5°	36.5°	57.6°
12 mm	47 mm	40.3°	30.8°	49.2°
15 mm	59 mm	32.7°	24.8°	40.3°
20 mm	79 mm	24.8°	18.7°	30.8°
25 mm	98 mm	20.0°	15.0°	24.8°
30 mm	118 mm	16.7°	12.6°	20.8°
40 mm	157 mm	12.6°	9.4°	15.7°
50 mm	197 mm	10.1°	7.6°	12.6°
70 mm	275 mm	7.2°	5.4°	9.0°
100 mm	393 mm	5.0°	3.8°	6.3°
150 mm	590 mm	3.4°	2.5°	4.2°

Depth of field table#

Total depth of field at each subject distance, using a circle of confusion of 7.6 µm (the 0.030 mm full-frame standard scaled by the crop factor).

Focal	Aperture	50.0 cm	1.00 m	2.00 m	3.00 m	5.00 m	10.0 m	Hyperfocal
6 mm	f/2	21.9 cm	1.02 m	11.8 m	∞	∞	∞	2.37 m
6 mm	f/2.8	32.1 cm	1.81 m	∞	∞	∞	∞	1.69 m
6 mm	f/4	50.8 cm	5.80 m	∞	∞	∞	∞	1.19 m
6 mm	f/8	2.80 m	∞	∞	∞	∞	∞	59.6 cm
11 mm	f/2	6.2 cm	25.3 cm	1.07 m	2.64 m	10.4 m	∞	7.94 m
11 mm	f/2.8	8.7 cm	36.0 cm	1.60 m	4.39 m	39.2 m	∞	5.68 m
11 mm	f/4	12.5 cm	53.2 cm	2.68 m	10.5 m	∞	∞	3.98 m
11 mm	f/8	26.3 cm	1.33 m	∞	∞	∞	∞	1.99 m
19 mm	f/2	2.0 cm	8.3 cm	33.7 cm	76.8 cm	2.20 m	10.3 m	23.7 m
19 mm	f/2.8	2.8 cm	11.6 cm	47.5 cm	1.09 m	3.23 m	18.1 m	16.9 m
19 mm	f/4	4.1 cm	16.7 cm	68.9 cm	1.61 m	5.12 m	58.5 m	11.9 m
19 mm	f/8	8.2 cm	34.1 cm	1.51 m	4.05 m	28.9 m	∞	5.94 m
31 mm	f/2	0.7 cm	3.1 cm	12.5 cm	28.3 cm	79.4 cm	3.25 m	63.0 m
31 mm	f/2.8	1.0 cm	4.3 cm	17.5 cm	39.8 cm	1.12 m	4.66 m	45.0 m
31 mm	f/4	1.5 cm	6.2 cm	25.1 cm	57.1 cm	1.62 m	7.03 m	31.5 m
31 mm	f/8	3.0 cm	12.4 cm	50.8 cm	1.17 m	3.50 m	21.1 m	15.8 m

Equivalent aperture#

Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.

Aperture on this camera	Full-frame equivalent (depth of field)	Hyperfocal at 11 mm
f/1.2	f/4.7	13.2 m
f/1.4	f/5.5	11.3 m
f/1.8	f/7.1	8.82 m
f/2	f/7.9	7.94 m
f/2.8	f/11.0	5.68 m
f/4	f/15.7	3.98 m
f/5.6	f/22.0	2.84 m
f/8	f/31.5	1.99 m

Diffraction & pixel pitch#

With 2.20 µm pixels, diffraction starts to soften pixel-level detail around f/3.3. For maximum sharpness keep landscapes between f/2.8 and f/3; stopping down further trades detail for depth of field.

Aperture	Airy disk diameter	Spread over	At 100% view
f/2.8	3.8 µm	1.7 px	sharp
f/4	5.4 µm	2.4 px	slight softening
f/5.6	7.5 µm	3.4 px	visibly soft
f/8	10.7 µm	4.9 px	visibly soft
f/11	14.8 µm	6.7 px	visibly soft
f/16	21.5 µm	9.8 px	visibly soft
f/22	29.5 µm	13.4 px	visibly soft

Maximum print sizes#

At 12 MP the Fujifilm XQ1 produces 4,000 × 3,000 pixel images. See the 12 megapixel guide or the print size calculator.

Resolution	Typical use	Inches	Centimetres
300 DPI	Photo-lab quality	13.3 × 10.0 in	34 × 25 cm
240 DPI	Fine-art inkjet	16.7 × 12.5 in	42 × 32 cm
200 DPI	Wall print	20.0 × 15.0 in	51 × 38 cm
150 DPI	Poster, viewed from 1 m+	26.7 × 20.0 in	68 × 51 cm

Night-sky exposure limits#

Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors.

Focal length	500 rule	NPF f/1.8	NPF f/2.8	NPF f/4
4 mm (16 mm eq.)	31.8 s	32.2 s	41.0 s	51.5 s
5 mm (20 mm eq.)	25.4 s	25.8 s	32.8 s	41.2 s
6 mm (24 mm eq.)	21.2 s	21.5 s	27.3 s	34.3 s
9 mm (35 mm eq.)	14.1 s	14.3 s	18.2 s	22.9 s
13 mm (51 mm eq.)	9.8 s	9.9 s	12.6 s	15.8 s

Open the NPF / 500 rule calculator →

Handheld shutter speed guide#

The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.

Focal length	No stabilisation (1/equiv. focal)	With 3-stop IS	With 5-stop IBIS
6 mm	1/25 s	0.3 s	1.3 s
13 mm	1/50 s	1/6 s	0.6 s
25 mm	1/100 s	1/13 s	0.3 s
51 mm	1/200 s	1/25 s	1/6 s

Lens#

The Fujifilm XQ1 has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 3.93.

Similar cameras#

Other 2/3" cameras from around the same time.

Frequently asked questions#

What is the crop factor of the Fujifilm XQ1?

The Fujifilm XQ1 has a crop factor of 3.93× relative to 35 mm full frame (diagonal 11.0 mm vs 43.3 mm).

What size is the Fujifilm XQ1 sensor?

8.8 × 6.6 mm (2/3"), an area of 58 mm² — 7% of full frame.

Is the Fujifilm XQ1 full frame?

No — its sensor is 2/3", which is 14.9× smaller in area than full frame.

How many megapixels does the Fujifilm XQ1 have?

12 megapixels (4,000 × 3,000 pixels), enough for a 13 × 10 inch print at 300 DPI.

How long can I expose the night sky with the Fujifilm XQ1?

With a 5 mm lens (20 mm equivalent) the 500 rule gives 25 s and the stricter NPF rule at f/2.8 gives 33 s.
