Specifications#
- Brand
- Fujifilm
- Model
- Instax
- Camera type
- Film camera
- Film format
- Instax Mini
- Image area
- 62.0 × 46.0 mm (6 × 4.5 cm (645) film)
- Crop factor
- 0.56×
Specifications merged from Wikipedia. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 0.56 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 21 mm | 12 mm | 111.8° | 95.2° | 122.9° |
| 23 mm | 13 mm | 106.9° | 90.0° | 118.4° |
| 28 mm | 16 mm | 95.8° | 78.8° | 108.1° |
| 32 mm | 18 mm | 88.2° | 71.4° | 100.7° |
| 35 mm | 20 mm | 83.1° | 66.6° | 95.6° |
| 45 mm | 25 mm | 69.1° | 54.1° | 81.2° |
| 55 mm | 31 mm | 58.8° | 45.4° | 70.1° |
| 63 mm | 35 mm | 52.4° | 40.1° | 63.0° |
| 80 mm | 45 mm | 42.4° | 32.1° | 51.5° |
| 90 mm | 50 mm | 38.0° | 28.7° | 46.4° |
| 110 mm | 62 mm | 31.5° | 23.6° | 38.7° |
| 120 mm | 67 mm | 29.0° | 21.7° | 35.7° |
| 150 mm | 84 mm | 23.4° | 17.4° | 28.9° |
| 180 mm | 101 mm | 19.5° | 14.6° | 24.2° |
| 250 mm | 140 mm | 14.1° | 10.5° | 17.6° |
| 350 mm | 196 mm | 10.1° | 7.5° | 12.6° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 53.5 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 38 mm | f/1.8 | 3.1 cm | 12.9 cm | 53.3 cm | 1.23 m | 3.72 m | 23.8 m | 15.0 m |
| 38 mm | f/2.8 | 4.8 cm | 20.2 cm | 85.0 cm | 2.04 m | 7.01 m | ∞ | 9.67 m |
| 38 mm | f/4 | 6.9 cm | 29.1 cm | 1.27 m | 3.27 m | 16.0 m | ∞ | 6.78 m |
| 38 mm | f/8 | 14.0 cm | 62.1 cm | 3.52 m | 23.1 m | ∞ | ∞ | 3.41 m |
| 77 mm | f/1.8 | 0.7 cm | 3.0 cm | 12.5 cm | 28.6 cm | 80.5 cm | 3.31 m | 61.6 m |
| 77 mm | f/2.8 | 1.1 cm | 4.7 cm | 19.5 cm | 44.6 cm | 1.26 m | 5.35 m | 39.6 m |
| 77 mm | f/4 | 1.5 cm | 6.7 cm | 27.9 cm | 64.0 cm | 1.84 m | 8.22 m | 27.8 m |
| 77 mm | f/8 | 3.1 cm | 13.4 cm | 56.6 cm | 1.33 m | 4.07 m | 29.5 m | 13.9 m |
| 131 mm | f/1.8 | 0.2 cm | 1.0 cm | 4.2 cm | 9.7 cm | 27.4 cm | 1.11 m | 178 m |
| 131 mm | f/2.8 | 0.3 cm | 1.5 cm | 6.5 cm | 15.0 cm | 42.6 cm | 1.74 m | 115 m |
| 131 mm | f/4 | 0.5 cm | 2.2 cm | 9.3 cm | 21.5 cm | 61.0 cm | 2.50 m | 80.3 m |
| 131 mm | f/8 | 0.9 cm | 4.3 cm | 18.7 cm | 43.2 cm | 1.23 m | 5.24 m | 40.2 m |
| 216 mm | f/1.8 | 0.1 cm | 0.3 cm | 1.5 cm | 3.4 cm | 9.9 cm | 40.4 cm | 484 m |
| 216 mm | f/2.8 | 0.1 cm | 0.5 cm | 2.3 cm | 5.4 cm | 15.4 cm | 62.9 cm | 312 m |
| 216 mm | f/4 | 0.1 cm | 0.7 cm | 3.3 cm | 7.7 cm | 22.0 cm | 90.0 cm | 218 m |
| 216 mm | f/8 | 0.3 cm | 1.4 cm | 6.6 cm | 15.3 cm | 44.0 cm | 1.81 m | 109 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 25 mm (14 mm eq.) | 35.7 s |
| 36 mm (20 mm eq.) | 24.8 s |
| 43 mm (24 mm eq.) | 20.7 s |
| 62 mm (35 mm eq.) | 14.4 s |
| 89 mm (50 mm eq.) | 10.0 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 43 mm | 1/25 s | 0.3 s | 1.3 s |
| 89 mm | 1/50 s | 1/6 s | 0.6 s |
| 178 mm | 1/100 s | 1/13 s | 0.3 s |
| 357 mm | 1/200 s | 1/25 s | 1/6 s |
Film stocks for the Fujifilm Instax#
Films currently made in 135 format.
- ADOX CHS 100 II ISO 100
- ADOX CMS 20 II PRO ISO 20
- ADOX Color Mission 200 ISO 200
- ADOX Color Mission Helios ISO 3
- ADOX HR-50 ISO 50
- ADOX Scala 50 ISO 50
- Agfa Copex Rapid ISO 50
- AgfaPhoto APX 100 ISO 100
- AgfaPhoto APX 200 ISO 200
- AgfaPhoto APX 400 ISO 400
- AgfaPhoto Color 400 ISO 400
- Argenti ARF+ Reporter Film Plus ISO 400
- Argenti Nanotomic X ISO 32
- Argenti Pan-X ISO 100
- Argenti Scale-X ISO 100
- Bergger Pancro 400 ISO 400
- CatLABS X FILM 320 ISO 320
- CatLABS X FILM 320 Pro ISO 320
Similar cameras#
Other 6 × 4.5 cm (645) film film cameras from around the same time.
- Mamiya 645 1975
Frequently asked questions#
What is the crop factor of the Fujifilm Instax?
The Fujifilm Instax has a crop factor of 0.56× relative to 35 mm full frame (diagonal 77.2 mm vs 43.3 mm).
What size is the Fujifilm Instax frame?
62.0 × 46.0 mm (6 × 4.5 cm (645) film), an area of 2852 mm² — 330% of full frame.
How long can I expose the night sky with the Fujifilm Instax?
With a 36 mm lens (20 mm equivalent) the 500 rule gives 25 s.
