Specifications#
- Brand
- Fujifilm
- Model
- FinePix S602 Zoom
- Camera type
- Compact
- Released
- 2002-01-01
- Sensor size
- 7.4 × 6.1 mm (1/1.7" sensor)
- Crop factor
- 4.49×
Specifications merged from Wikidata, Lensfun and openMVG. Spot an error? Tell us.
Sensor size compared#
Focal length equivalents & field of view#
Multiply any focal length by 4.49 to get the full-frame field of view. For fixed-lens cameras use the real focal length printed on the lens (e.g. “6.1–18.3 mm”), not the 35 mm equivalent.
| Lens on this camera | Full-frame equivalent | Horizontal | Vertical | Diagonal |
|---|---|---|---|---|
| 4 mm | 18 mm | 85.8° | 74.9° | 100.6° |
| 4.5 mm | 20 mm | 79.2° | 68.5° | 93.9° |
| 5 mm | 22 mm | 73.3° | 63.0° | 87.9° |
| 6 mm | 27 mm | 63.6° | 54.1° | 77.6° |
| 8 mm | 36 mm | 49.9° | 41.9° | 62.1° |
| 10 mm | 45 mm | 40.8° | 34.1° | 51.5° |
| 12 mm | 54 mm | 34.4° | 28.7° | 43.8° |
| 15 mm | 67 mm | 27.9° | 23.1° | 35.6° |
| 20 mm | 90 mm | 21.1° | 17.4° | 27.1° |
| 25 mm | 112 mm | 16.9° | 14.0° | 21.8° |
| 30 mm | 135 mm | 14.1° | 11.7° | 18.3° |
| 40 mm | 180 mm | 10.6° | 8.8° | 13.7° |
| 50 mm | 224 mm | 8.5° | 7.0° | 11.0° |
| 70 mm | 314 mm | 6.1° | 5.0° | 7.9° |
| 100 mm | 449 mm | 4.3° | 3.5° | 5.5° |
| 150 mm | 673 mm | 2.8° | 2.3° | 3.7° |
Depth of field table#
Total depth of field at each subject distance, using a circle of confusion of 6.7 µm (the 0.030 mm full-frame standard scaled by the crop factor).
| Focal | Aperture | 50.0 cm | 1.00 m | 2.00 m | 3.00 m | 5.00 m | 10.0 m | Hyperfocal |
|---|---|---|---|---|---|---|---|---|
| 5 mm | f/2 | 28.5 cm | 1.48 m | ∞ | ∞ | ∞ | ∞ | 1.88 m |
| 5 mm | f/2.8 | 43.0 cm | 3.35 m | ∞ | ∞ | ∞ | ∞ | 1.34 m |
| 5 mm | f/4 | 73.6 cm | ∞ | ∞ | ∞ | ∞ | ∞ | 94.0 cm |
| 5 mm | f/8 | ∞ | ∞ | ∞ | ∞ | ∞ | ∞ | 47.3 cm |
| 10 mm | f/2 | 6.6 cm | 26.9 cm | 1.15 m | 2.85 m | 12.0 m | ∞ | 7.49 m |
| 10 mm | f/2.8 | 9.2 cm | 38.4 cm | 1.73 m | 4.89 m | 73.1 m | ∞ | 5.35 m |
| 10 mm | f/4 | 13.3 cm | 56.9 cm | 2.97 m | 13.3 m | ∞ | ∞ | 3.75 m |
| 10 mm | f/8 | 28.1 cm | 1.47 m | ∞ | ∞ | ∞ | ∞ | 1.88 m |
| 17 mm | f/2 | 2.2 cm | 9.1 cm | 37.0 cm | 84.4 cm | 2.43 m | 11.7 m | 21.6 m |
| 17 mm | f/2.8 | 3.1 cm | 12.8 cm | 52.2 cm | 1.20 m | 3.60 m | 22.2 m | 15.5 m |
| 17 mm | f/4 | 4.5 cm | 18.3 cm | 75.9 cm | 1.79 m | 5.85 m | 126 m | 10.8 m |
| 17 mm | f/8 | 9.0 cm | 37.6 cm | 1.70 m | 4.76 m | 61.5 m | ∞ | 5.42 m |
| 28 mm | f/2 | 0.8 cm | 3.3 cm | 13.5 cm | 30.5 cm | 85.4 cm | 3.50 m | 58.7 m |
| 28 mm | f/2.8 | 1.1 cm | 4.6 cm | 18.9 cm | 42.8 cm | 1.20 m | 5.05 m | 41.9 m |
| 28 mm | f/4 | 1.6 cm | 6.6 cm | 27.0 cm | 61.4 cm | 1.75 m | 7.69 m | 29.4 m |
| 28 mm | f/8 | 3.2 cm | 13.3 cm | 54.8 cm | 1.27 m | 3.83 m | 25.3 m | 14.7 m |
Equivalent aperture#
Exposure is identical at the same f-number on any format; equivalence only describes depth of field and total light.
Night-sky exposure limits#
Longest exposure before stars trail. The NPF rule accounts for pixel pitch and is stricter than the classic 500 rule — use it for pin-sharp stars on high-resolution sensors. (NPF needs a known resolution and is omitted here.)
| Focal length | 500 rule |
|---|---|
| 4 mm (18 mm eq.) | 27.9 s |
| 5 mm (22 mm eq.) | 22.3 s |
| 6 mm (27 mm eq.) | 18.6 s |
| 8 mm (36 mm eq.) | 13.9 s |
| 11 mm (49 mm eq.) | 10.1 s |
Handheld shutter speed guide#
The reciprocal rule uses the equivalent focal length. High-resolution sensors may need one stop faster than this for pixel-sharp results.
| Focal length | No stabilisation (1/equiv. focal) | With 3-stop IS | With 5-stop IBIS |
|---|---|---|---|
| 5 mm | 1/25 s | 0.3 s | 1.3 s |
| 11 mm | 1/50 s | 1/6 s | 0.6 s |
| 22 mm | 1/100 s | 1/13 s | 0.3 s |
| 45 mm | 1/200 s | 1/25 s | 1/6 s |
Lens#
The Fujifilm FinePix S602 Zoom has a built-in, non-interchangeable lens. Use the real focal length of that lens with the tables above; its full-frame equivalent is that number × 4.49.
Similar cameras#
Other 1/1.7" cameras from around the same time.
Frequently asked questions#
What is the crop factor of the Fujifilm FinePix S602 Zoom?
The Fujifilm FinePix S602 Zoom has a crop factor of 4.49× relative to 35 mm full frame (diagonal 9.6 mm vs 43.3 mm).
What size is the Fujifilm FinePix S602 Zoom sensor?
7.4 × 6.1 mm (1/1.7"), an area of 46 mm² — 5% of full frame.
Is the Fujifilm FinePix S602 Zoom full frame?
No — its sensor is 1/1.7", which is 18.9× smaller in area than full frame.
How long can I expose the night sky with the Fujifilm FinePix S602 Zoom?
With a 5 mm lens (22 mm equivalent) the 500 rule gives 22 s.
